Martin VC-Dot 4 [新品]

VC-Dot 4 is a lightweight string of individually controllable, bright Dots useful in creating customized LED video solutions with maximum artistic flexibility and a minimum of effort. Fully customizable and controllable via the award-winning P3 System Controller™ family and/or DMX512, it is a perfect solution for integrating LED video technology into façades, stage designs, ceilings or any other structure, indoors or out.

Mapping video onto VC-Dots goes quickly and intuitively via the P3 System Controller. No need for complex setups and time-consuming addressing. VC-Dot 4 contains four LEDs and is available in an RGB color mixing version.

・Creative LED Video element for building and stage integration
・Customizable pixel-pitch
・Bright and fully calibrated for optimal consistency

・Flexible string-based direct-view LED lighting
・Perfect for façade or stage integration
・Individually controllable VC-dots
・Up to 64 VC-dots per string
・Customizable VC-dot pixel pitch and string length
・Calibrated brightness and colors for each VC-Dot
・P3 and RDM/DMX controllable
・Intuitive mapping and addressing via P3 System Controller family
・Efficient and long-lasting
・IP67 rated for permanent outdoor or indoor use
・Simple infrastructure via VC-Feeder and P3 PowerPort
・Great number of mounting options using clips, brackets or profiles

・Pixel dimensions: 36 x 30 x 13 mm
・Pixel dimensions with dome: 36 mm x 30 mm x 27 mm
・Weight: 1.8 kg for 64 Dots, 200 mm spacing, with 2 m (6.6 ft.) lead-in cable and connector
・Maximum number of pixels per string: 64
・Standard pixel spacing (pitch): 200 mm
・Minimum pixel spacing (pitch): 110 mm
・Maximum pixel spacing (pitch): 2000 mm
・Standard lead-in cable length: 2000 mm
・Maximum lead-in cable length: 5000 mm
・One pixel = one Dot

・Control options: Martin™ P3 System controller and/or DMX
・Control modes: Calibrated and raw
・Control resolution: 16-bit (P3) or 8-bit (DMX) control of each color
・Setting and addressing: P3 System Controller or RDM-compliant controller
・DMX channels: 3 per RGB Dot, string or group
・Color and intensity calibration: Dot-level
・DMX compliance: USITT DMX512-A
・RDM compliance: ANSI/ESTA E1.20

・Minimum LED lifetime: 50,000 hours (to >70% luminous output)*
・LED manufacturer: Cree
 *Figure obtained under manufacturer´s test conditions

・Light source : Four RGB LEDs
・Viewing angle: 127° x 127°
・Viewing angle with dome: 180° x 180°
・Luminous intensity, RGB, calibrated mode: 6 cd
・Luminous intensity, RGB, raw mode: 7.5 cd
・Total output, RGB, calibrated mode: 18.8 lm
・Red output, RGB, calibrated mode: 5.2 lm
・Green output, RGB, calibrated mode: 12.3 lm
・Blue output, RGB, calibrated mode: 1.4 lm

・Dot: Clear polycarbonate, clear silicone filled
・Diffuser dome: White translucent polycarbonate
・Mounting clip: White polycarbonate
・Interconnecting cable: 6 x 20 AWG, black
・Minimum cable bend radius: 26 mm (1.1 in.)
・Protection rating: IP67
・RoHS compliant

・Orientation: Any

・Power & data input to VC-Dot string from VC-Feeder™: Custom 8-pin connector, IP67-rated

・Operating voltage: 15 VDC
・Power and data converter: Martin VC-Feeder™
・Peak power consumption (at full intensity, full white): 1.50 W per Dot
・Typical power consumption (with typical video content): 0.50 W per Dot
・Figures for typical video content are indicative only and will vary.

・Cooling: Convection
・Maximum ambient temperature (Ta max.): 55° C
・Minimum ambient temperature (Ta min.): -20° C
・Peak heat dissipation (calculated, at full intensity, full white): 6.5 BTU/hr.
・Typical heat dissipation (calculated, with typical video content): 2.5 BTU/hr.
・Figures for typical video content are indicative only and will vary.
