Robe BMFL Washbeam [中古:ITEM#31552]

Robe BMFL Washbeam [中古:ITEM#31552]

販売価格: 799,990円(税別)

(税込価格: 879,989円)

The strong-arm of the BMFL? family - the superbly powerful BMFL WashBeam comes with extra bright output and an abundance of great features, e.g newly developed framing shutters, super wide front lens and animation wheel.

■特徴
・LIGHT SOURCE 1700 W OSRAM Lok-it! HTI 1700/PS
・LIGHT OUTPUT 41.000 lm, 300.000 lx @ 5 m, 3.000 lx @ 50 m
・ZOOM RANGE 5° - 45°
・EFFECTS framing shutters, rotating gobo wheel, interchangeable frost

■■仕様
■SOURCE
・Lamp: Compact short-arc metal halide lamp
・Base: PGJX28
・Approved model: OSRAM Lok-it! HTI 1700/PS
・Lifetime: 750 hours @ 1700 W / 1500 W / Quiet mode
・CRI 92+
・Colour temperature: 6.000 K
・Control: Automatic and remote on/off
・Ballast: Electronic

■OPTICAL SYSTEM
・Robe’s proprietary optical design
・High - efficiency zoom optical system, ratio 9:1
・Zoom range: 5° - 45°
・Output lens diameter: 180 mm
・Dichroic glass reflector for maximising the light efficiency
・High efficient component optics
・Fixture total lumen output
・41.000 lm at 1.700 W
・38.130 lm at 1.500 W
・33.620 lm at 1.200 W (Quiet mode)
・Light output: 300.000 lx @ 5 m, 3.000 lx @ 50 m

■DYNAMIC EFFECTS
・Cyan: 0-100 %
・Magenta: 0-100 %
・Yellow: 0-100 %
・Variable CTO: 2.700-6.000 K
・Colour wheel 1: 6 fixed dichroic colours - deep red, deep blue, orange, green, magenta, congo blue + white
・Colour wheel 2: 6 replaceable "SLOT&LOCK" dichroic colours - pink, lavender, laser green, 9.000 K CTB, minus half and minus green + white
・Framing shutters: 4 individually positionable blades plus rotation of the complete frame system +-45°
・Rotating gobo wheel: 6 rotating, indexable, replaceable "SLOT&LOCK" glass gobos + open
・Aluminium animation wheel: used alone or in combination with gobos, rotating in both directions at variable speed
・Iris: Motorized, stepless, pulse effects up to 3 Hz
・Frost: Variable Light, Medium plus replaceable Heavy (two another frosts included)
・Motorized zoom and focus
・Shutter: Separate dual blade system, Variable strobe effect up to 10 Hz, full black out
・Dimmer: Optimized dual blade system for exceptional smooth dimming

■CONTROL AND PROGRAMMING
・Setting & Addressing: ROBE Navigation System 2 (RNS2)
・Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding
・Protocols: USITT DMX-512, RDM, Art-Net, MA Net, MA Net2, sACN
・Web server
・Wireless version: CRMX? technology from Lumen Radio
・DMX Protocol modes: 2
・Control channels: 48, 41
・Pan/Tilt resolution: 16 bit
・CMY & CTO: 8 bit
・Colour wheel positioning: 8 or 16 bit
・Framing shutters system: 8 bit
・Rotating gobo wheel positioning: 8 bit
・Gobo indexing & rotation: 8 or 16 bit
・Animation wheel: 8 bit
・Animation wheel rotation: 8 bit
・Iris: 8 or 16 bit
・Frost: 8 bit
・Zoom: 8 or 16 bit
・Focus: 8 or 16 bit
・Dimmer: 8 or 16 bit

■MOVEMENT
・Pan movement: 540°
・Tilt movement: 270°
・Movement control: Standard and Speed
・Controllable speed of Pan/Tilt movement
・EMS?: Electronic Motion Stabilizer system for Pan & Tilt reducing beam deviation caused by truss movement or vibration (Patent pending)
・Automatic Pan/Tilt position correction

■ROTATING GOBOS
・6x rotating glass gobos
・Outside diameter: 30.8 mm
・Image diameter: 25.0 mm
・Thickness: 1.1 mm
・Max. thickness: 3.5 mm
・High temperature borofloat or better glass

■EFFECT WHEEL
・Single animation wheel
・Material: Aluminium
・Diameter: 109 mm
・Can be used alone or in combination with rotating gobos
・Rotating in both directions, variable speed

■FRAMING SHUTTERS SYSTEM
・Blade: 4 Blades, each with separate movement and rotation control
・Movement: Smooth with variable speed, ultrafast blade movements for creating mid-air effects
・Pre-programmed: Shape and blade sequences
・Rotation: 90° of the complete framing system

■THERMAL SPECIFICATION
・Maximum ambient temperature: 45 °C (113 °F)
・Maximum surface temperature: 170 °C (338 °F)
・Minimum operating temperature: -5°C (23°F)

■ELECTRICAL SPECIFICATION AND CONNECTIONS
・Power supply: Electronic auto-ranging
・Input voltage range: 200-240 V, 50/60 Hz
・Power consumption: 2000 W at 230 V / 50 Hz
・Power in connector: Neutrik powerCON
・DMX and RDM data in/out: Locking 3-pin & 5-pin XLR
・Ethernet port in: RJ45

■APPROVALS
・cETLus Compliant
・CE Compliant

■MECHANICAL SPECIFICATION
・Height: 826 mm (32.5")
・Width: 483 mm (19.0")
・Depth: 335 mm (13.2")
・Weight: 38.4 kg (84.7 lbs)
・Ingress protection rating: IP20

■RIGGING
・Mounting positions: 0°, 32°, 90°
・Universal operating position
・Mounting points: 5 pairs of 1/4-turn locks
・2x Omega adaptors with 1/4-turn quick locks
・Safety cable attachment point
・Pan and Tilt transport locks

■データシート(英語)
https://cdn.robe.cz/fileadmin/user_upload/product_pdf/en_bmfl_washbeam.pdf

■マニュアル(英語)
https://www.robe.cz/index.php?type=10898&tx_odproducts_f%5baction%5d=downloadFile&tx_odproducts_f%5bfile%5d=robe/downloads/user_manuals/User_manual_Robin_BMFL_WashBeam.pdf

■メーカーサイト
https://www.robe.cz/bmfl-washbeam/
