Arri ARRIMAX 18/12 [新品]

The original Academy Award-winning ARRIMAX remains the ultimate choice for productions requiring maximum light output. The 580 mm (22.8”) diameter, parabolic facetted reflector provides continuous focus adjustment from 15° to 50° beam angle and, since the ARRIMAX does not require a set of spread lenses, shadows are sharp and easily cut.

Safe and easy for both lamp type bases 18/12 kW, 18,000 W single ended lamps use a sturdier GX51 lamp base for which ARRI engineers have designed a special lampholder that alleviates mechanical stress from the lamp pins, now serving only as an electrical connection. The lamp clamping mechanism is self-aligning and uses a rugged, recessed lamp lock handle. To ensure that crews can easily use 12,000 W lamps or versions of 18,000 W single ended lamps with G38 bases, the new lampholder accepts either lamp type with no modification or adjustment.

■概要
・Lens-less MAX Technology
・15° to 50° continuous beam angle: standard reflector
・8° to 15° beam angle: spot reflector
・Easy re-lamping
・ARRI Dual Pin Width support (GX51/GX38)
・IP Rating IP23
・Suitable for high frame rate images
・Works with motorized yoke "BigBee"

■詳細
・SeriesM-Series
・ModelARRIMAX 18/12
・Mains PlugVEAM
・Lamphead TypeOpen Face with Facetted Reflector, 12,000 / 18,000 W
・ReflectorMAX Technology reflector made of high purity aluminium
・Lamp TypeMetal Halide 18,000 W/SE; Metal Halide 12,000 W/SE
・Power Consumption18,000 W / 12,000 W
・Voltage Range225 V / 160 V
・Lamp BaseGX51 / GX38
・Dimmingyes, 50 to 100 % via ARRI Ballast Unit
・Correlated Color Temperatureapprox. 5,600 K
・Beam Angle15° to 50° (with 18,000 W lamp)
・Weight in kg net*approx. 70 kg
・Weight in kg packed*approx. 99 kg
・Measurements (HxWxL) incl. Pin in mm*1270 x 784 x 942 mm
・Measurements (HxWxL) excl. Pin in mm*1155 x 784 x 942 mm
・Measurements (HxWxL) Packed size in mm*1050 x 1170 x 1135 mm
・Lens / UV-Protection Glass Diameter in mm646 mm
・Accessory Diameter in mm740 mm
・Barndoor in mm740 mm
・MountingSpigot 28 mm
・Housing ColorBlue/Silver
・Protection Class / IP RatingI / IP23
・CertificationsCE, CB, GS, cNRTLus

■データシート(英語PDF)
https://www.arri.com/resource/blob/31498/e061ffb5f0c5c494445352e5fda1cf64/arri-m-series-arrimax-data-sheet-en-sep2018-data.pdf

■メーカーサイト
https://www.arri.com/en/lighting/daylight/m-series/arrimax-18-12
