Martin RUSH Scanner 1 LED [新品]

The RUSH Scanner 1 LED is designed to enable lighting designers to boost the wow factor and energize crowds with high-speed mid-air looks in a variety of entertainment venues and nightclubs.

This fixture delivers high output via sharp optics and is packed with eye-catching effects. With its high-speed pan and tilt capabilities, the RUSH Scanner 1 LED is ideal for creating dramatic atmospheres and boosting energy levels on cruise ships, in dance clubs and other nightlife venues.

Compact size, low weight, rugged construction and long-life LEDs also make the RUSH Scanner 1 LED a favorite for rental companies seeking to produce once-in-a-lifetime memorable events through powerful, dynamic lighting effects.

■概要
・Powerful 90 W white LED engine
・Breathtakingly fast pan and tilt
・Rich, dynamic feature set including two color wheels, two gobo wheels and rotating prism

■特徴
・High-power, long-life 90 W white LED engine
・Effects include two gobo wheels. two color wheels and a 3-facet prism
・Sharp projections with motorized focus
・DMX control and standalone operation
・Auto trig and music trig standalone modes
・Compact size and rugged construction

■■仕様
■PHYSICAL
・Length: 588 mm
・Width: 303 mm
・Height: 193 mm
・Weight: 9.6 kg

■DYNAMIC EFFECTS
・Electronic shutter effect: Strobe, pulse effects, instant open and blackout
・Electronic dimming: 0 - 100%, four dimming curve options
・Color wheel 1: 8 colors plus open, rotation with variable direction and speed
・Color wheel 2: 8 colors (incl. 1 x UV, 2 x CTC) plus open, rotation with variable direction and speed
・Rotating gobo wheel: 6 rotating/indexing gobos plus open
・Focus: Motorized
・Prism: Indexing and rotation with variable direction and speed
・Fixed gobo wheel: 7 gobos plus open
・Pan: 170°, coarse & fine control
・Tilt: 75°, coarse & fine control

■CONTROL AND PROGRAMMING
・Control options: DMX, standalone, synchronized master/slave
・Setting and addressing: Control panel with backlit LCD display
・DMX channels: 16
・Standalone trigger options: Sound activation (music trig), auto trig
・Standalone sequences: 9 pre-programmed shows
・Standalone memory: 20 scenes
・Music trig sensitivity: Adjustable
・DMX compliance: USITT DMX512/1990

■OPTICS
Light source: 90 W LED engine
Minimum LED lifetime: 30,000 hours (to >70% luminous output)*
Rotating gobo size : 24 mm (0.94 in.)
Rotating gobo image size : 20 mm (0.79 in.)
 *Figure obtained under manufacturer's test conditions.

■CONSTRUCTION
・Housing: High-impact flame-retardant thermoplastic
・Color: Black
・Protection rating: IP20

■INSTALLATION
・Mounting points: Adjustable bracket, surface or truss mount
・Location: Indoor use only, must be fastened to surface or structure
・Orientation: Any

■CONNECTIONS
・AC power in, thru: Neutrik PowerCon
・DMX data in/out: 3-pin and 5-pin locking XLR

■ELECTRICAL
・AC power: 100-240 V nominal, 50/60 Hz
・Power supply unit: Auto-ranging electronic switch mode
・Power Consumption: 168 W
・Fuse: T 6.3 A
・Typical half-cycle RMS inrush current: 10 A

■TYPICAL POWER AND CURRENT
・100 V, 60 Hz: 1.7 A, 170 W, PF 0.997
・120 V, 60 Hz: 1.4 A, 165 W, PF 0.994
・230 V, 50 Hz: 0.7 A, 162 W, PF 0.937
・Figures obtained at nominal voltage. Figures are typical, not maximum, allow for +/- 10% variation.

■THERMAL
・Cooling: Forced air
・Maximum ambient temperature (Ta max.): 40° C (104° F)
・Minimum ambient temperature (Ta min.): 0° C (32° F)
・Total heat dissipation (calculated, +/- 10%): 570 BTU/hr. (at full intensity)

■データシート
https://adn.harmanpro.com/site_elements/executables/14473_1531164770/RUSH-Scanner-1-LED_original.pdf

■マニュアル
https://adn.harmanpro.com/site_elements/executables/6809_1526699780/UM_RUSHScanner1LED_EN_B_original.pdf

■メーカーサイト
https://www.martin.com/en/products/rush-scanner-1-led

19,950円 (税別) 以上 送料無料
