ACME SPARKLING（スパークリング） [AM3]

SPARKLING is small and portable, with powerful light output, energy saving and environmental protection, integrates powerful beam and washing functions. Adopts 19pcs 15W RGBA LED, individual control of each RGBA pixel. With circular reflector mirror,can create mirrorball effect with beam light spotting on the mirror. Equipped with an electronic linear zoom system, the zoom range is 10°~60°, and the color is stable and uniform in the dimming range, easy to create a wonderful dynamic world. Outstanding strobe effect with variable speed, 0-100% smooth dimming, to meet the washing effect of wider applications.


Features

Light source: 19x15W RGBA LED
With powerful beam and wash effects
Individual control of each RGBA pixel
Outstanding color macro effect
Electronic linear zoom system
Zoom range: 10°~60°
With circular reflector mirror,can create mirrorball effect with beam light spotting on the mirror
Outstanding strobe effect with variable speed
0~100% smooth dimming
Fast and mute operating
Flicker free management
Dust-proof and oil-proof design

Model

AM3

Light source

Light source: 19x15W RGBA LED
LED life expectancy: 20000 hours

Optical system

Advanced optical system to ensure clear and large-range beam & wash effect
High - efficiency zoom optical system, ratio 1:6
Zoom range: 10° - 60°

Control and Program

4-buttons
Display: LCD display
Protocols: DMX512, RDM
DMX Protocol modes: 4
Control channels: 11,14,15,23
Pan/Tilt Resolution: 16 bit
Dimmer: 16 bit
Upgrade the firmware via DMX link & USB

PAN & TILT

Pan movement: 540°
Tilt movement: 240°
Automatic Pan/Tilt position correction

Electrical and Connectors

Power supply with electronic auto-ranging
Input voltage range: 100-240V~ 50/60Hz
Power consumption: 300 W
Power Connector Input
Data in/out: 3-pin or 5-pin XLR

Fixture Specification

Height: 398 mm (15.6")
Width: 197 mm (7.7")
Depth: 310 mm (12.2")
Weight: 8.6 kg (18.9 lbs)

Work Environment

Maximum ambient temperature: 40°C
Maximum surface temperature: 65°C
Minimum operating temperature: 0°C

Approvals

CE Compliant

Installation

Horizontally or vertically mounting are available
Operating position is universal
2 pairs of 1/4-turn locking points under the base
2 x fast-locked clamps with 1/4-turn locks for 50 millimeter truss
Safety Rope Hole

Included Items

Circular reflector mirror
Digital User Manual
Power Cable
2 pairs of 1/4-turn locking points under the base

Optional Accessories (with item code)

Raincover：3033001749
Clamps：2060001632（C-250B）
Signal Line：3-pin or 5-pin signal line
Safety cable : 2060000200（SW-02）
