ACME LYRA WASH（ライラ ウォッシュ） [XA 1000 BW IP]

LYRA WASH brings a new generation of highly enhanced wash and beam technology and a without-comparison light out a step further to you.

Featuring an eye-catching 180mm lens 1,000 W LED source, with a highly efficient zoom system of 4.5°– 60°, an exceptionally tight, harsh and defined beam as weel as wide and even wash coverage. This high-CRI engine ensures accurate color reproduction delivered in the most shining output over 56,000 lumens. When light designers want to tone it down and bath in soft light, the 0~100% linear diffusion filter will craft a gradient and much smoother light at any degree you like. Four framing system modules at ±60° allow easily for fast and accurate geometrical forms. An uncommon design of not one, but 1 color wheel and rotating gobo wheel conmbine to create a deeper idea of a playful stage. Designed to be sealed against water and particle ingress, LYRA WASH with its IP66 rating is fearless and confident in strict outdoor conditions.

This lightweight, outdoor wash&beam knows how to work out the best shot of light in the stage.


Features

Diameter of Front Lens: 180mm
Standard Mode: Ra>70
HCRI Mode: Ra>90
HCRI Filter used to switch to HCRI mode
Linear CMY color mixing
Linear CTO color correction: 2,700K-6,700K
1 Color wheel: 5 colors, 1 HCRI filter, plus open, with bidirectional rainbow effects
1 Rotating gobo wheel: 6 High-precision gobos, plus open
New material patented diffusion filter can achieve 0~100% linear softening effect and make the spot larger and more uniform
Framing: 4 fast and smooth framing shutters. Each shutter blade position and angle can be controlled individually, the framing module can be rotated at ±60°
Variable light adjustment from 0-100% dimming
Outstanding strobe effect with variable speed
IP 66 rating

Model

XA 1000 BW IP

Light Source

Light Source: 1000W LED Engine
Color Temperature Output: 6,700K
Total Lumen Output: 56,000lm
Rated Source Life: up to 20,000 hours*

Optical System

Beam angle: 4.5°-40°
Field angle：5°-60°
Diameter of Front Lens: 180mm

Control and Program

4-Button touch panel
Display: LCD display
Protocols: DMX512, RDM
DMX Protocol modes: 2
Control channels: 30/18
Firmware Upgrade: Upgrade via DMX link

Pan & Tilt

Pan movement: 540°
Tilt movement: 260°
Automatic Pan/Tilt position correction
Fixation: Pan/ Tilt lock
Moving-head operated with either 16-bit resolution

Gobos

1 x Rotating gobo wheel: 6 High-precision gobos, plus open

Color

Smooth CMY Color Mixing
Linear CTO Color Correction: 2,700K-6,700K
1 Color wheel: 5 colors, 1 HCRI filter, plus open, with bidirectional rainbow effects

Other Effects

New material patented diffusion filter can achieve 0~100% linear softening effect and make the spot larger and more uniform
Framing: 4 fast and smooth framing shutters. Each shutter blade position and angle can be controlled individually, the framing module can be rotated at ±60°
Variable light adjustment from 0-100% dimming
Outstanding strobe effect with variable speed

Electrical and Connectors

Input voltage range: 100-240V~ 50/60Hz
Power consumption: 1,455 W
Power In/Out: Power Connector in/out
Date In/Out: 3-pin or 5-pin XLR

Fixture Specification

Fixture Dimensions:
Width: 412 mm (16.2")
Depth: 330 mm (13.0")
Height: 743 mm (29.3")
Weight: 41.5 kg (89.3 lbs)
Flight Case Dimensions:
Width: 1,143 mm (45.0")
Depth: 812 mm (32.0")
Height: 840 mm (33.0")
Weight: 182.2 kg (402 lbs)(Dual Loader Case)
Carton Specification:
Width: 630 mm (24.8")
Depth: 520 mm (20.5")
Height: 715 mm (28.1")
Weight: 48 kg (105.8 lbs)(include carton, one-pack per carton)

Work environment

Maximum ambient temperature: 40°C
Minimum operating temperature: -10°C
Maximum surface temperature: 65°C
Protection rating: IP66

Installation

Horizontally or vertically mounting are available
Universal working position
2x omega brackets
Safety cable attachment hole

Included Items

Digital User Manual
Power Cable
2x omega brackets

Optional Accessories (with item code)

Flight Case: 3205110026
Signal Line: 3-pin or 5-pin signal line
Safety cable: 2060001603A(SW-05)
Clamps: 2060001614(C-250B)
