ACME DOTLINE360（ドットライン 360） [TB-1230 QW]

ACME's creative Dotline360 is a high-power performance fixture equipped with 12x 30WRGBW LEDs, packed tightly to give a full linear light from a 1 meter bar. Its quality optical design offers excellent color mixing and smooth output across the two independent zoom zones ,one of the remarkable functions of Dotline. What's more, it offers full pixel mapping capabilities. With a 1:11 zoom ratio from 3.5-38˚, it ranges from a very narrow-angle light curtain effect to a wide-angle wash bar. The unique fast-lock system and turnable clamp enables rapid setup in any trussing, saving production time.

Features

Light Source: 12x30W RGBW LED
Zoom range: 3.5-38°
Effects:The zoom angle of the right and left modules can be individually controlled for outstanding color mixing effects and adjustable strobe speeds
Efficient cooling: 4x silent fans are evenly distributed beneath the fixture, while both sides and the bottom plate are vented to improve convection cooling, quickly removing the heat generated by the LEDs and greatly improving their efficiency
Connected quantity:
Maximum QTY of DMX connecting mode: 32 sets
Maximum QTY of Power supply connecting mode:120V - 4 sets / 230V - 7 sets

Model

TB-1230 QW

Light Source

Light Source: 12x30W RGBW LED
LED life expectancy: 30,000 hours

Optical System & Effects

Zoom range: 3.5-38°
RGBW color mixing
Individual control of zoom angles of left and right modules
Outstanding color mixing effect with variable speed
High resolution dimmer 0–100%

Electromechanical Effects

Linear motorized zoom
Tilt movement range: 220°

Control & Program

4-button touch panel
Display: OLED display
Battery backup for user setup without mains connection
Protocols: DMX512, RDM, Art-Net
DMX Protocol modes: 2
Control channels: 14, 57
Firmware upgrade via DMX link

Electrical & Connectors

Power supply with electronic auto-ranging
Input voltage range: 100-240V~ 50/60Hz
Power consumption: 440W
Power in/out: Power Connector in/out
Data in/out: 3-pin & 5-pin XLR

Fixture Specification

Height: 113mm (4.4”)
Width: 278mm (10.9”)
Depth: 1000mm (39.3”)
Weight: 17kg (37.4lb)

Work environment

Maximum ambient temperature: 40°C
Maximum surface temperature: 65°C
Minimum operating temperature: 0°C

Approvals

CE compliant

Installation

Horizontal or vertical mounting
Operating position is universal
2x fast-lock clamps for 50mm truss
Safety Rope Hole

Included items

Digital User Manual
Power Cable
Carry handles (minimum load 60kg)
Safety rope device
2x fast-lock clamps for 50mm truss

Optional Accessories (with item code)

Vertical raincover: 3033002024
Invert raincover: 3033002025
Flight case: 3205001222 (4 in 1)
Clamp: 2060001632 (C-250B)
Safety cable: 2060000200 (SW-02)
Signal Line: 3-pin or 5-pin signal line
