GLP FUSION Exo Beam 10（フュージョン Exo ビーム 10）

販売価格はお問い合わせください。

返品特約に関する重要事項

商品詳細

FUSION by GLP’s Exo Beam 10 is a powerful IP65 rated Moving Head with a beam angle of just 1°, generating a sharp beam that can be seen for long distances.

The Exo Beam 10 features a single, powerful and highly efficient 90 W, 7,500 K white light LED engine.

With its 160 mm front lens, the fixture features an incredible 1° beam angle and a field angle of just 1° along with incredibly fast pan and tilt movements, combining to give incredible mid air effects – either indoor, or out.

The powerful beam fixture comes equipped with a range of additional effects, including two independent rotating prisms that can be used individually, or combined together for stunning aerial effects; a hybrid gobo wheel with both static and rotating gobos; a color wheel with 14 colors; as well as motorized focus, variable speed shutter and 16 bit pan and tilt movement.

The versatile fixture can operate anywhere in the world, and in any orientation with wireless DMX control available as an optional extra. With a robust die cast housing which combined with the IP65 rating make the Exo Beam 10 ready for even the worst of outdoor conditions.

仕様

■Light Source
Type
White Light LED-Engine
Light Source Count
1
Light Source Power
90 W
Light Source Lifetime
20,000 h
Optical System
Output
2,300 lm
Beam angle
fixed, 1°
Focus
motorized
2m – infinite
Output Lens Diameter
160 mm / 6.3 in
Effects
Dimmer / Shutter
0 – 100% electronic
regular and random strobe and pulse effects
Prism
6-way linear
rotating
Prisma 2
8-way
rotating
Gobo Wheel 1
7 rotating + 7 fixed Gobos + open
rotatable and indexable
Color Wheel
14 dichroic color filters + open
Pan
540°
Tilt
239°
Control
DMX channels
15
Control Modes
1
Protocol
DMX (USITT DMX512-A)
RDM (ANSI/ESTA E1.20)
Display
self charging buffer battery
OLED display with 4 buttons
Wireless
Lumenradio CRMX DMX/RDM (optional)
Software Update
DMX link
Dimming Curves
linear
soft
Fan Modes
regulated
high
medium
low
Connectors
Signal connection
XLR 5-Pin
In/Out
Power input
Neutrik powerCON TRUE1
In/Out
Electrical Specifications
Power input
100 – 240 VAC / 50 – 60Hz
Power supply
auto-ranging electronic switch-mode
Fuse
T5A 250 V
max. power (@230V)
185 W, 0.8 A
Thermal Specifications
Cooling
temperature controlled, overheating protection
max. ambient temperature (Ta max.)
45°C / 113°F
min. ambient temperature (Ta min.)
-20°C / -4°F
Total heat dissipation (calculated, +/-10%)
630 BTU/h
Mounting Options
Mounting
2 pair of 1/4-turn locks
Rubber feet
eyelets for safety cable
Orientation
any
Location
Outdoor temporary
min. distance to combustible materials
0.5 m / 18.7 in
Construction
Housing Color
Black
Housing Material
Aluminum
Protection Rating
IP 65
Construction Features
Pan-Tilt-Lock-System
Shipping
Single fixture
cardboard
