Chauvet Professional Rogue Outcast 1 Hybrid [新品]

Chauvet Professional Rogue Outcast 1 Hybrid [新品]

販売価格はお問い合わせください。

Rogue Outcast 1 Hybrid is an outdoor-ready, IP65 spot/beam/wash moving head ideal for small to medium festivals and events. Powered by an intense 400W lamp, Rogue Outcast 1 Hybrid delivers a 6500K output with tight beam angles of 2° to 14° in Beam Mode and a zoom range of 5° to 31° in Spot Mode and 10° to 25° in Wash Mode for maximum visual impact. This feature-packed unit offers 1 rotating and 1 static gobo wheel, 2 individually controllable 8 and 5-facet layerable prisms, and a 14-hue color wheel for solid and split colors. Control is over DMX and RDM.

■特徴
・Fully featured, IP 65 rated, high powered Spot/Beam/Wash combination fixture with an USHIO 400W, 6500K with 6000 Hour life expectancy lamp, 2 gobo wheels, 2 layerable prisms, and linear zoom
・Rugged housing designed to withstand the elements in a temporary outdoor setting
・Individually controllable and layerable 6 facet linear and 8 facet round prisms for maximizing visual impact
・Frost and beam flattening options for even light distribution
・Tight 2° narrow beam angle for focused air effects
・Linear zoom of 2 ° to 15° in beam mode, 3.7° to 26.6° in spot mode and 9.3° to 26.1° in wash mode for coverage in any application
・9 rotating and 13 static gobos for massive visual effect
・DMX and RDM protocol control
・True 1 compatible power input

■■仕様
■OPTICAL
・Light Source: USHIO NSL-400 W lamp, 6632 K, 6,000 hours life expectancy
・Color Temperature (at full): 6632 K
・Beam Angle: 2° to 13.5° (Spot mode)
・Field Angle: 3.7° to 26.6° (Spot mode)
・Beam Angle: 1° to 5° (Beam mode)
・Field Angle: 2° to 15° (Beam mode)
・Beam Angle: 4.9° to 18.7° (Wash mode)
・Field Angle: 9.3° to 26.1° (Wash mode)
・Zoom Angle (Spot mode): 3.7° to 26.6°
・Zoom Angle (Beam mode): 2 ° to 15°
・Zoom Angle (Wash mode): 9.3° to 26.1°
・Lumens ? Source: 14,575
・Lumens ? Output: 12,575
・Illuminance (3.7°): 277,135 lux @ 5 m (Spot mode)
・Illuminance (26.6°): 5145 lux @ 5 m (Spot mode)
・Illuminance (2°): 144,000 lux @ 15 m (Beam mode)
・Illuminance (15°): 3210 lux @ 15 m (Beam mode)
・Illuminance (9.3°): 15,090 lux @ 5 m (Wash mode)
・Illuminance (26.1°): 1,337 lux @ 5 m (Wash mode)

■DYNAMIC EFFECTS
・Pan and Tilt: 540°/260°
・Pan and Tilt Ranges: 540°, 360°, 180° pan/260°, 180°, 90° tilt
・Colors: 13 + white, split colors, continuous scroll at variable speeds
・Gobos (1): 9 + open (9 glass), continuous scroll at variable speeds
・Gobos (2): 13 + open (13 metal), rotating, interchangeable, indexing, continuous scroll at variable speeds
・Gobo Size: Gobo Wheel 1 (rotating glass): 15.9 mm (outside), 12 mm (image), 1.1 mm (max. thickness)
・Dimmer: Motorized
・Shutter/Strobe: Motorized
・Zoom: Motorized
・Focus: Motorized
・Frost: Motorized
・Prism: 6 Facets, motorized, rotating
・Prism: 8 Facets, motorized, rotating
・Move-in-Black: Yes

■CONSTRUCTION / PHYSICAL
・Dimensions: 412 x 310 x 765 mm
・Weight: 38 kg
・Exterior Color: Black
・Housing Material: Aluminum die-cast

■CONNECTIONS
・Power Connection: Bare-wired to Seetronic Powerkon IP65
・Power Input: Seetronic Powerkon IP65
・Data Connectors: 5-pin IP rated
・Cable Length (power): 5 ft (1.5 m)

■CONTROL
・Control Protocol: DMX, RDM
・DMX Channels: 20 or 25
・Modes/Personalities: 2 personalities (20, 25)

■ELECTRICAL
・Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
・Power and Current: 514 W, 4.329 A @ 120 V, 60 Hz
・Power and Current: 513 W, 2.501 A @ 208 V, 60 Hz
・Power and Current: 520 W, 2.267 A @ 230 V, 50 Hz

■CERTIFICATIONS / QUALIFICATIONS
・CE, MET
・IP Rating: IP65, temporary outdoor/wet use
・Temperature (Ambient): 14 °F to 104 °F (-10 °C to 40 °C)

■WHAT'S INCLUDED
・Rogue Outcast Hybrid IP
・Seetronic Powerkon IP65 power cord
・2 Omega brackets with mounting hardware
・Quick Reference Guid

■リファレンスガイド
https://www.chauvetprofessional.com/wp-content/uploads/2020/02/Rogue_Outcast_1_Hybrid_QRG_ML5_Rev1.pdf

■メーカーサイト
https://www.chauvetprofessional.com/products/rogue-outcast1-hybrid/
