SGM G·Wash [新品]

The G-Wash is a multi-environmental, maintenance-free RGB LED moving head with an IP65-rating. With one of the widest zoom ranges ever seen in a Fresnel-based wash luminaire, the G-Wash is able to create extremely bright colors from long distances with noiseless operation and accurate beam distribution. The integrated dehumidifier of the G-Wash ensures perfect inner cleanness of the luminaire and no accumulation of dust or externally induced impact on internal optics, gobos, or the light source unit.

■概要
・High-power IP65 RGB Fresnel LED light source
・Practically maintenance-free and silent performance
・13500 lumen and 9° to 73° zoom range
・Optional rotating and indexable beam shaper
・DMX, RDM, and wireless control
・2000K - 10000K CTC control, no hotspots
・Ultra-high-speed strobe effect
・Flicker-free / Programmable scenes

■サイズ
・Weight: 49.00 kg
・Dimensions: 585 x 821 x 492 mm

■■仕様
■Optical Data
・Fresnel lens diameter 200 mm
・LED expected lifetime 50,000 hours
・Lightsource High-power RGB LED
・Zoom Motorized
・Zoom range 9° to 73°

■Photometric
・Color temperature range 2000K - 10000K
・Efficacy 19 lm/W
・Light output all LEDs on 13500 lm
・Light output blue 1400 lm
・Light output green 3800 lm
・Light output red 3800 lm
・Lux @ 10m 2593 lux

■Physical
・Color options
 Black - RAL 9004
 Custom color - Any RAL
 White - RAL 9010
・IP class IP65
・Lens materialTempered glass front
・Material Aluminium Plastic PA6.6Steel
・Net dimensions 585 x 821 x 492 mm
・Net weight49 kg

■Features
・Beam shaper Rotating and indexable
・Dehumidifier Base / Head
・Dimming Electronic
・Pan 540°
・Strobe Ultra-high-speed strobe effects
・Tilt 270°
・Variable aperture Intensity optimized / projection optimized

■Electrical
・AC power, max. 190 - 264V 50/60Hz
・AC Power, nominal 208 - 240V 50/60Hz
・Electrical Protection Overload protectionMain fuseT12A - 250V
・Max Inrush Current 230VAC 30 A
・Max power consumption 1050 W
・Power factor 0.99 PF (230 V) PF (230V)
・Power Supply Unit Auto-ranging electronic switch-mode
・Standby power consumption 70 W
・Typical power consumption 750 W

■Programming and Control
・16-bit control Dimmer, colors, pan/tilt, zoom, beam shaper
・Cabled DMX 5 pin XLR input/output
・DMX channels 16 or 19
・DMX modes 2
・Protocol USITT DMX512A Wireless DMX (LumenRadio)RDM ANSI E1.20
・Setting and addressing Control panelOLED graphical display / 4 buttonsRDM ANSI E1.20RFID
・Standalone mode Up to 24 programmable scenes
・Wireless DMX Lumen Radio with RDM

■Connections
・DMX data in/out IP65 XLR 5-pin cable, 0,2 m (7.8 in)
・Power Power input connector

■Installation
・Mounting point 4 x 2 quarter-turn locking points
・Orientation Any
・Rigging possibilitiesHanging (Omega Brackets included)
・Safety features 2 attachment points for safety wire Minimum distance to combutible materials: 0.3 meter (11 in).

■Thermal
・Cooling Active, Forced Air, Temperature-regulated
・Humidity (max.) 98 %
・Temperature range, Operating -40°C to 50°C
・Temperature range, Start-up -20°C to 50°C
・Temperature range, Storage -40°C to 80°C
・Thermal Protection Automatic overtemperature protection

■Included items
・Included items 2 Omega bracket with quater-turn fasteners2 m power cableSafety instructions and installation quick guide

■Conforms To
・CE - 2014/30/EU: EMC Directive
 EN 55103-1EN 55103-2EN 61000-3-2EN 61000-3-3
・CE - 2014/35/EU: Low Voltage Directive
 EN 60598-1EN 60598-2-17EN 62471EN 60529
・RoHS2 Directive2011/65/EU
・UL UL Std. 1573

■Certified To
・CSA CSA E60598-1, Ed: 2CSA-E598-2-17-98, Ed: 1

■メーカーサイト
https://sgmlight.com/products/entertainment/g%C2%B7wash
