SGM G·4 Wash-Beam [新品]

The G-4 Wash-Beam is a fast and compact wash moving light capable of outstanding color rendering and a sharp defined beam angle. The optical system is designed to deliver a high-quality color mix with an accurate and precise beam of light. Because of its remarkable output, wide zoom range, qualified color reproduction, accurate color temperature control, and low power consumption, the G-4 Wash-Beam is a very flexible moving light suitable for any application.

■概要
・High-power IP65 LED Wash-Beam moving head
・Superb color mixing based on Red, Green, Blue, Amber, and Mint LEDs
・Best-in-class color rendering index: TLCI > 90, CRI > 92, CQS > 91, Rf > 89
・Accurate zoom range from 4.8º beam angle to 34º field angle
・2000K - 10000K CTC linear control with optimized color rendering
・DMX, RDM, and wireless control
・Practically maintenance-free and silent performance
・Flicker-free / programmable scenes / continuous pan movement

■サイズ
・Weight: 10.00 kg
・Dimensions: 219 x 537 x 255 mm

■■仕様
■Optical Data
・LED expected lifetime 50,000 hours
・Lens diameter 136 mm
・Lightsource 5 color 150 W
・Zoom Motorized
・Zoom range 4.8° to 34°

■Photometric
・Color temperature range 2000K - 10000K
・CQS typical 91
・CRI @ 3200K 94
・CRI @ 5600K 92
・CRI typical 92
・Efficacy 27.7 lm/W
・Light output all LEDs on 5738 lm
・Lux @ 10m 2047 lux
・Lux @ 3m 22740 lux
・Lux @ 5m 8190 lux
・Maximum Beam Angle 30 °
・Maximum Field Angle 34 °
・Minimum Beam Angle 4 °
・Minimum Field Angle 7 °
・RF typical (TM-30-15) 89
・TLCI @ 3200K 87
・TLCI @ 5600K 93
・TLCI typical 90

■Physical
・Color options
 Black - RAL 9004
 Custom color - Any RAL
 White - RAL 9010
・IP class IP65
・Material AluminiumPC/ASAPlasticRubberSteel
・Net dimensions219 x 537 x 255 mm
・Net weight10 kg

■Features
・Dehumidifier Head
・Dimming Electronic
・Emulation mode / effect Color Filter Emulation
・PanEndless Pan modes 360° 360° Shortest path540°Continues CCWContinues CWEndless
・Strobe Ultra-high-speed strobe effects
・Tilt 220°
・Variable aperture Optimized Beam Narrow / Optimized Beam Wide

■Electrical
・AC power, max. 90 - 264V 50/60Hz
・AC Power, nominal 100 - 240V 50/60Hz
・Electrical Protection Overload protection with automatic recover
・Max Inrush Current 230VAC40 A
・Max power consumption 250 W
・Power Supply Unit Auto-ranging electronic switch-mode
・Standby power consumption 18 W
・Typical power consumption 200 W

■Programming and Control
・16-bit control Dimmer, colors, pan/tilt
・Cabled DMX 5 pin XLR input/output
・DMX channels 18
・DMX modes 1
・Protocol CRMX, W-DMX™ G2, W-DMX™ G3, W-DMX™ G4, W-DMX™ G4SUSITT DMX512ARDM ANSI E1.20
・Setting and addressing Control panelRDM ANSI E1.20
・Standalone mode 8 Internal Standalone Programs9 Internal Pan/Tilt Presets
・Wireless DMX Lumen Radio with RDM

■Connections
・DMX data in/out IP65 XLR 5-pin cable, 0,2 m (7.8 in)IP65 XLR 5-pin connector, Male
・Power Power input connector

■Installation
・Mounting point 2 quarter-turn locking points for one Omega bracket
・Orientation Any
・Rigging possibilities Hanging (Omega Bracket included) or ceiling/wall mount (optional)
・Safety features 2 attachment points for safety wireMinimum distance to combutible materials: 0.3 meter (11 in).

■ThermalCoolingActive, Forced Air, Temperature-regulatedHumidity (max.)98 %Temperature range, Operating-40°C to 50°CTemperature range, Start-up-20°C to 50°CTemperature range, Storage-40°C to 80°CThermal ProtectionAutomatic overtemperature protection

■Included items
・Included items2 m power cable1 Omega bracket with quater-turn fasteners

■Conforms To
・CE - 2014/30/EU: EMC Directive
 EN 55103-2EN 55015EN 61547EN 61000-3-2EN 61000-3-3EN 55032
・CE - 2014/35/EU: Low Voltage Directive
 EN 60598-1EN 60598-2-17EN 62471EN 60529RoHS2 Directive2011/65/EUULUL Std. 1573

■Certified To
・CSA CSA Std. C22.2 No. 166

■Flexible, Powerful, Superior: The SGM G-4(動画)
https://vimeo.com/210733252

■メーカーサイト
https://sgmlight.com/products/entertainment/g%C2%B74-wash-beam
