SGM G·4 Wash Motorized Barndoors [新品]

The G-4 Wash Motorized Barndoors is an accurate and compact fresnel moving light, capable of outstanding color rendering and precise manipulation of beam angle. The optical system is designed to deliver a perfect color mix with a completely even field and no hotspots. Because of its controllable external barndoors, wide zoom range, qualified color reproduction, accurate color temperature control, and low power consumption, the G-4 Wash Motorized Barndoors is a must-have for stages, theatres, and TV / film studios.

■概要
・High-power LED Fresnel Wash moving head with external motorized barndoors
・Superb color mixing based on Red, Green, Blue, Amber, and Mint LEDs
・Best-in-class color rendering index: TLCI > 90, CRI > 92, CQS > 91, Rf > 89
・4 individual DMX-controllable blades with +/- 110º rotation and 9° to 76° zoom range
・2000K - 10000K CTC linear control with optimized color rendering
・DMX, RDM, and wireless control
・Practically maintenance-free and silent performance
・Flicker-free / programmable scenes / continuous pan movement

■サイズ
・Weight: 11.90 kg
・Dimensions: 219 x 494 x 258 mm

■■仕様
■Optical Data
・Fresnel lens diameter 112 mm
・LED expected lifetime 50,000 hours
・Lightsource5 color 150 W
・Zoom Motorized
・Zoom range 9° to 76°

■Photometric
・Color temperature range 2000K - 10000K
・CQS typical 91
・CRI @ 3200K 94
・CRI @ 5600K 92
・CRI typical 92
・Efficacy 35 lm/W
・Light output all LEDs on 7265 lm
・Light output blue 264 lm
・Light output green 1103 lm
・Light output red 524 lm
・Lux @ 10m 757 lux
・Lux @ 3m 7720 lux
・Lux @ 5m 3027 lux
・Maximum Beam Angle 52 °
・Maximum Field Angle 78 °
・Minimum Beam Angle 9 °
・Minimum Field Angle 20 °
・RF typical (TM-30-15) 89
・TLCI @ 3200K 87
・TLCI @ 5600K 93
・TLCI typical 90

■Physical
・Color options
 Black - RAL 9004
 Custom color - Any RAL
 White - RAL 9010
・IP class IP65 (Fixture), IP20 (Motorized Barndoor)
・Lens material Tempered glass front
・Material AluminiumPC/ASAPlasticRubberSteel
・Net dimensions 219 x 494 x 258 mm
・Net weight11.9 kg

■Features
・Dehumidifier Head
・Dimming Electronic
・Emulation mode / effect Color Filter Emulation
・Filters Soft diffusion external filter
・Framing 4 external controllable motorized barndoors, adjustable +/-150°Rotatable external barndoors module +/-110°
・Pan Endless
・Pan modes 360°360° Shortest path540°Continues CCWContinues CWEndless
・Strobe Ultra-high-speed strobe effects
・Tilt 220°
・Variable aperture Optimized Beam Narrow / Optimized Beam Wide

■Electrical
・AC power, max. 90 - 264V 50/60Hz
・AC Power, nominal 100 - 240V 50/60Hz
・Electrical Protection Overload protection with automatic recover
・Max Inrush Current 40 A
・Max power consumption 250 W
・Power Supply Unit Auto-ranging electronic switch-mode
・Standby power consumption 18 W
・Typical power consumption 200 W

■Programming and Control
・16-bit control Dimmer, colors, pan/tilt
・Cabled DMX 5 pin XLR input/output
・DMX channels 23
・DMX modes 1
・Protocol CRMX, W-DMX™ G2, W-DMX™ G3, W-DMX™ G4, W-DMX™ G4SUSITT DMX512ARDM ANSI E1.20
・Setting and addressing Control panelOLED graphical display / 4 buttonsRDM ANSI E1.20
・Standalone mode 8 Internal Standalone Programs9 Internal Pan/Tilt Presets
・Wireless DMX Lumen Radio with RDM

■Connections
・DMX data in/out IP65 XLR 5-pin cable, 0,2 m (7.8 in)IP65 XLR 5-pin connector, Male
・Power Power input connector

■Installation
・Mounting point 2 quarter-turn locking points for one Omega bracket
・Orientation Any
・Rigging possibilities Hanging (Omega Bracket included) or ceiling/wall mount (optional)
・Safety features 2 attachment points for safety wireMinimum distance to combutible materials: 0.3 meter (11 in).

■Thermal
・Cooling Active, Forced Air, Temperature-regulated
・Humidity (max.) 80 %
・Temperature range, Operating -40°C to 50°C
・Temperature range, Start-up -20°C to 50°C
・Temperature range, Storage -40°C to 80°C
・Thermal Protection Automatic overtemperature protection

■Included items
・Included items 2 m power cable1 Omega bracket with quater-turn fastenersSoft diffusion external filterSafety instructions and installation quick guide

■Conforms To
・CE - 2014/30/EU: EMC Directive
 EN 55103-2EN 55015EN 61547EN 61000-3-2EN 61000-3-3EN 55032
・CE - 2014/35/EU: Low Voltage Directive
 EN 60598-1EN 60598-2-17EN 62471
・RoHS2 Directive 2011/65/EU

■SGM G·4 Wash Motorized Barndoors(動画)
https://vimeo.com/298148173

■メーカーサイト
https://sgmlight.com/products/entertainment/g%C2%B74-wash-motorized-barndoors
