The G-1 Wash moving head is the ideal companion for the G-1 Beam, and is designed for any type of outdoor event and smaller venues in need of small moving wash lights with high output, uniform colors from a distance and color calibration to match other SGM fixtures. The G-1 Wash offers high contrast levels and extreme brightness in a small physical footprint at a low power consumption. The G-1 Wash can be ordered with or without batteries, installed with a remote base, or without any base at all.

■概要
・Battery-driven IP65 color LED moving head
・19 RGBW LEDs and a 8.5? beam angle
・Continuous pan movement, built-in macro effects
・DMX, RDM and 100% wireless (power and control)
・Extremely bright with full color mixing
・Ultra-high-speed strobe effect
・Practically maintenance-free and silent performance
・Flicker-free / Programmable scenes

■サイズ
・Weight: 8.90 kg
・Dimensions: 219 x 382 x 255 mm

■■仕様
■Optical Data
・LED expected lifetime 50,000 hours
・Lens 8.5°
・Lens angle 8.5 °
・Lightsource 19 LEDs total, 4 Red, 4 Green, 4 Blue, 7 White (5.700K)

■Photometric
・Beam angle(s) 8° (with 8.5°)
・Color temperature range 2000K - 10000K
・Efficacy 38 lm/W
・Lux @ 10m 549 lux
・Lux @ 3m 5078 lux
・Lux @ 5m 2194 lux
・Maximum Beam Angle 8 °
・Maximum Field Angle 8.5 °

■Physical
・Color options
 Black - RAL 9004
 Custom color - Any RAL
 White - RAL 9010
・IP class IP65
・Material Aluminium PC/ASAPlasticRubberSteel
・Net dimensions 219 x 382 x 255 mm
・Net weight8.9 kg

■Features
・Built-in macro effects 50 macros
・Dimming Electronic
・Pan Endless
・Pan modes 360° 360° Shortest path 540°Continues CCW Continues CW Endless
・Strobe Ultra-high-speed strobe effects
・Tilt 240°

■Electrical
・AC power, max. 90 - 264V 50/60Hz
・AC Power, nominal 100 - 240V 50/60Hz
・DC power, nominal 24 VDC
・Electrical Protection Overload protection with automatic recover
・Max Inrush Current 230VAC 35 A
・Max power consumption 55 W
・Power Supply Unit Auto-ranging electronic switch-mode
・Standby power consumption 7 W
・Typical power consumption 40 W

■Programming and Control
・16-bit control Dimmer, pan and tilt
・Cabled DMX 5 pin XLR input/output
・DMX channels 13
・DMX modes 1
・Protocol CRMX, W-DMX? G2, W-DMX? G3, W-DMX? G4, W-DMX? G4SUSITT DMX512ARDM ANSI E1.20
・Setting and addressing Control panel OLED graphical display / 4 buttonsRDM ANSI E1.20Standalone mode
・Standalone mode 8 Internal Standalone Programs9 Internal Pan/Tilt Presets
・Wireless DMX Lumen Radio with RDM

■Connections
・DMX data in/out IP65 XLR 5-pin cable, 0,2 m (7.8 in)IP65 XLR 5-pin connector, Male
・Power Power input connector

■Installation
・Mounting point 2 quarter-turn locking points for one Omega bracket
・Orientation Any
・Rigging possibilities Hanging (Omega Bracket included) or ceiling/wall mount (optional)
・Safety features 2 attachment points for safety wireMinimum distance to combutible materials: 0.3 meter (11 in).

■Thermal
・Cooling Passive
・Humidity (max.) 98 %
・Temperature range, Operating -40°C to 50°C
・Temperature range, Start-up -20°C to 50°C
・Temperature range, Storage -20°C to 25°C
・Thermal Protection Automatic overtemperature protection

■Included items
・Included items 2 m power cable1 Omega bracket with quater-turn fastenersSafety instructions and installation quick guide

■Battery
・Battery capacity (non-stop) 6 - 8 hours
・Battery capacity (typical use) 12 - 14
・Battery charge time up to 100% 12 - 16 hours
・Battery charge time up to 75% 8 - 12 hours
・Battery Option YES
・Battery status Battery level indicator
・Battery type Lithium-Ion battery
・Memory effect 85% battery capacity after 500 full charge cycles

■Conforms To
・CE - 2014/30/EU: EMC Directive
 EN 55103-1EN 55103-2EN 55015EN 61547EN 61000-3-2EN 61000-3-3
・CE - 2014/35/EU: Low Voltage Directive
 EN 60598-1EN 60598-2-17EN 62471EN 60529RoHS2 Directive2011/65/EUULUL Std. 1573
