HIGHLITE Showtec Media Panel 100 CCT [33303]

Showtec - Media Panel 100 CCT. Product code 33303 from Highlite International on Vimeo.

100 W Tunable White Media Panel
Suitable for short-distance media lighting
Wide 120° beam angle
High >96 CRI for accurate 3000 K to 5600 K colour rendering
DMX-controllable (5-pin XLR)

仕様

Source
Light Source Type
LED
Light Source Quantity
392
Light Source Power
0.5 W
LED Colour Type
WW, CW
Illuminance @ 2 m
650 lx
Illuminance @ 3 m
289 lx
Illuminance @ 5 m
104 lx
Luminous Flux (Total)
6650 lm
CRI
96
Minimum CCT
3000 K
Maximum CCT
5600 K

Optical
Beam Angle (Circular)
120°
Field Angle (Horizontal)
160°

Control and Programming
Control Mode
DMX, Manual
Protocols
DMX, RDM
Display
OLED

Electrical Specifications and Connections
Power Supply
24 V DC
Power Consumption
100 W
Power Connector In
Low Voltage DC plug
DMX Connector
XLR 5P In/Out
DMX Connector In
XLR 5P
DMX Connector Out
XLR 5P

サイズ

Mechanical Specifications
Length (mm)
480 mm
Width (mm)
70 mm
Height (mm)
340 mm
Weight
2.4 kg
IP Rating
IP20 (indoor use only)
Housing
Aluminium
Colour
Dark Gray

Product Properties
Cooling
Convection
Type Floodlight
Symmetric

Rigging
Mounting Options
Bracket

Thermal Specifications
Maximum Ambient Temperature
45 °C

Included Items
Included Cables
IEC cable
Included Accessories
Adapter, Barndoor, Spigot Adapter 16 mm (5/8)

参照

■メーカーサイト
https://www.highlite.com/en/products/entertainment-lighting/flood-lights/flood-lights-white/33303-media-panel-100-cct.html
