Jands Stage CL Console [中古:ITEM#30569]

Jands Stage CL Console [中古:ITEM#30569]

販売価格: 219,990円(税別)

(税込価格: 241,989円)

数量:
The Jands Stage CL is a lighting control console intended for the control of intensity-only fixtures and multi-colour LEDs. It has been specifically designed and optimised for easy control of full colour LED fixtures for all users from beginners to the advanced professional.

■概要
・Dedicated colour controls per fixture
・ 24 Fixtures in two pages of 12 *
・Integrated RGB mimic LED per channel
・ Single Preset operation
・ Dedicated scene controls
・Dedicated cuelist and controls
・ One-touch chase programming
・ Both single colour and striped Presets
・ Dedicated chase controls and flexible operation modes
・ Fixtures libraries can be built on the console
・ Software Updatable without opening the chassis
・ DMX-512 and Ethernet (Artnet, sACN) output
・ 480x272 pixel TFT graphics touch screen
・ Audio trigger from inbuilt microphone
・ Tap synchronisation of chases
・ Backup to USB Flash drive
・ Spreadsheet style patch
・ Multiple colour fan modes
・ High speed ARM9 processor
・ Universal input DC power supply
・ Ethernet port including indicator LEDs
・ Storage for multiple shows in the console
・ Power switch and indicator LED
・ Integrated cable retention
・ Kensington lock point
・ VESA mount enables mounting on standard monitor arms
・ Integrated carry handle

■仕様
・ Power supply : 12VDC +/-10% 2A
・ Power consumption : 24W max
・ Mains connector : 5.5/2.1mm coaxial DC power socket
・ Processor : Atmel ARM9
・ DRAM : 128MB
・ FLASH : 256MB
・ Ambient temperature: 0°C-40°C
・ Graphics Display : 4.3 inch (480x272) TFT
・ Touch screen : Resistive
・ Maximum Fixtures : 24
・ DMX512 : 5 pin AXR
・ Ethernet : 100Mbit RJ45
・ USB : Two Type A High Speed
・ VESA Mount : 100mm x 100mm
・ Dimensions : 520 x 300 x 70 mm
・ Net/shipping weight : 4.5**/5.8 kg
* Value does not include multi-patched fixtures
** Net weight includes one IEC cable, shipping weight includes two

■スペックシート(英語)
https://www.jands.com/downloads/stagecl/TSS-JND-Stage-CL-1408-05.pdf

■公式サイト
https://jands.com/stage-cl/

■公式Video
https://player.vimeo.com/video/70306165?color=db443b?title=0&byline=0&portrait=0&color=bc161c
