Chauvet Professional Maverick Storm 1 Flex（マーベリック ストーム1 フレックス）

概要

Outperform expectations with the intense brightness of this compact member of our Maverick Storm family of lighter, brighter, stadium-power moving heads built to rugged IP65 standards. No lamp. No hot spot. Only perfectly even output at every angle from a multifunctional LED powerhouse. Maverick Storm 1 Flex goes flat out from narrow beams to wide spots, while producing excellent color rendering and offering lighting designers a full effects wheelhouse for layering gobo, prism and animation effects. Draw on Maverick Storm 1 Flex to release stunning textured looks, send totally solid beams and hit the deepest colors.

特徴

Fully featured, IP65 rated, high powered Spot/Beam/Wash combination fixture with a 520W LED source, CMY+CTO color mixing, an animation wheel, 2 gobo wheels, 2 layerable prisms, large zoom range, and lightweight aluminum/magnesium housing

16-bit dimming of master dimmer for smooth control of fades

Variable CMY + CTO color mixing system to create a wide palette of colors

CRI and CTB filters on color wheel for added flexibility

1 rotating and 1 static gobo wheel

An animation wheel for kinetic textured effects

Tight 2.6° narrow beam angle for focused air effects

7 rotating and 10 static gobos for massive visual effect

DMX, CRMX, sACN, and Art-Net for full flexibility of control options

RDM control over DMX for fixture reporting

True 1 compatible power input

Integrated sun shield for protecting the optical path from sunlight when the fixture is off

Three setup menu presets and preset sync for cross loading to multiple like fixtures for easy shop setup

USB-C slot for software uploads

Battery backup display with auto-rotate depending on fixture orientation

Failsafe Ethernet connectivity allows for data to pass even if fixture power is lost

Built in Sky Tracker mode allows for up to 4 fixtures to work together to create sky tracker effects

仕様

Optical
Light Source: 1 Led, 6595K, up to 50,000 hours life expectancy**Test lab conditions. May vary depending on several factors including but not limited to:Environmental conditions, power/voltage, usage patterns, (on/off power cycling), control, and dimming.Color Temperature (at full): 6595 KFront lens diameters: 165 mmBeam Angle: 3.1° to 46.6° (Spot mode)Field Angle: 4.1° to 57.9° (Spot mode)Cutoff Angle: 4.5° to 55.5 ° (Spot mode)Beam Angle: 2.6° to 43 ° (Beam mode)Field Angle: 3° to 47.3° (Beam mode)Cutoff Angle: 3.4° to 50.7° (Beam mode)Beam Angle: 2.8° to 45.8 ° (Wash mode)Field Angle: 3.7° to 53.1° (Wash mode)Cutoff Angle: 3.9° to 57° (Wash mode)Zoom Range: 3.1° to 55.5° (Spot mode)Zoom Range: 2.6° to 50.7° (Beam mode)Zoom Range: 2.8° to 57° (Wash mode)Lumens : 33587 lmIlluminance : (3.1 °) 154,697 lux @ 5 m (Spot mode)Illuminance : (55.5 °) 2,675 lux @ 5 m (Spot mode)Illuminance : (2.6°) 17,538 lux @ 15 m (Beam mode)Illuminance : (50.7 °) 295 lux @ 15 m (Beam mode)Illuminance : (2.8°) 146,171lux @5 m (Wash mode)Illuminance : (57 °) 2478 lux @ 5 m (Wash mode)
Dynamic Effects
Pan and Tilt: 540°/270°Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tiltColors: 7 + white, split colors, continuous scroll at variable speedsColors: CMY flagsGobos (1): 7+ open (1 empty slot + 6 glass, rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds) and (1) steel dual layer non-removable rotating, continuous scroll at variable speeds)Gobos Static: 10 + open (11 metal), rotating, continuous scroll at variable speedsGobo Size (1): Gobo Wheel 1 (rotating): 23.9 mm (outside), 20 mm (image), 1.1 mm (max. thickness)Animation Wheel: 1Dimmer: MotorizedShutter/Strobe: MotorizedZoom: MotorizedFocus: MotorizedFrost: MotorizedPrism (1): 6 Facets, motorized, rotatingPrism (2): 8 Facets, motorized, rotatingMove-in-Black: YesBuilt in Sky Tracker Mode: Yes
Construction / Physical
Dimensions: 15.27 x 10.55 x 10.55 in (388 x 268 x 738 mm)Weight: 63.5lb (28.8 kg)Exterior Color: BlackHousing Material: Aluminum die-cast, High-impact flame-retardant polymer, Steel
Connections
Power Connection: Seetronic Powerkon IP65Power Input: Seetronic Powerkon IP65Data Connectors: 5-pin IP rated XLR, Seetronic IP rated RJ45 Connectors in/outCable Length (power): 5 ft (1.5 m)Software Connection: Type-C USB
Control
Control Protocol: Art-Net, sACN, RDM, DMX, CRMXDMX Channels: 26 or 33Art-Net/sACN Channels: 26 or 33Modes/Personalities: 2 personalities (26, 33)
Electrical
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)Power and Current: 754 W, 6.25 A @ 120 V, 60 HzPower and Current: 734 W, 3.60 A @ 208 V, 60 HzPower and Current: 738 W, 3.30 A @ 230 V, 50 Hz
Certifications / Qualifications
CE, MET, FCC, CB, UKCAIP Rating: IP65, outdoor/wet, with pressure equalizing M12 GORE valveTemperature (Ambient): 14 °F to 113 °F (-10 °C to 45 °C)
What's Included
Maverick Storm 1 FlexSeetronic Powerkon IP65 power cord to Edison Plug(2) 140 Omega brackets with mounting hardware
Optional Accessories
ClampsPowerKon IP65 cablesetherCON cables5 Pin DMX CablesFlight Cases

■メーカーサイト
https://www.chauvetprofessional.com/products/maverick-storm-1-flex/
