HIGHLITE Showtec Cameleon Flood 6 Q4 RGBW [42672v]
商品詳細
6x 5 W RGBW LED Flood
IP65 (dust and water resistant, fit for outdoor use)
40° fixed beam angle
Dimmer and strobe effects
Manual, DMX, IR and Master/Slave control
The Showtec Cameleon Flood 6 Q4 is a 6x 5 watt RGBW LED Flood with IP65 rating, suitable for indoor and outdoor applications. It has a 40° fixed beam angle and features 0 - 100 % dimmer and 0 - 15 Hz strobe effects. The Cameleon Flood 6 Q4 can be controlled manually, via DMX, Master/Slave and IR Remote in either Manual or Auto run mode with many available built-in programs. It comes with a dedicated IP65 power connector and bracket. An infrared remote is optional.
Light Source Type
LED
Light Source Quantity
6
Light Source Power
5 W
LED Colour Type
RGBW
Refresh Rate
1200 Hz
Luminous Flux (Total)
1337 lm
Luminous Flux (Red)
324 lm
Luminous Flux (Green)
754 lm
Luminous Flux (Blue)
124 lm
Luminous Flux (White)
579 lm
Optical
Beam Angle (Horizontal)
40°
Beam Angle (Vertical)
40°
Control and Programming
Control Mode
Auto, DMX, Manual, Master Slave
DMX Channels
4, 6, 10
Protocols
DMX
Display
OLED, Touch
Dim Curve
Linear, Square, I-Square, S-Curve
Dynamic Effects
Dimmer
0-100 %
Strobe
0-15 Hz
Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
35 W
Power Connector In
Dedicated IP65 Powerconnection
Power Connector Out
Dedicated IP65 Powerconnection
DMX Connector
Dedicated 3P IP65 In/Out
DMX Connector In
Dedicated 3P IP65
DMX Connector Out
Dedicated 3P IP65
Cable Length
1.5 m
Length (mm)
220 mm
Width (mm)
90 mm
Height (mm)
150 mm
Weight
2.66 kg
IP Rating
IP65
Housing
Aluminium die-cast
Colour
Black
Product Properties
Cooling
Convection
Rigging
Mounting Options
Clamp
Safety Attachment
Yes
Thermal Specifications
Maximum Ambient Temperature
40 °C
Maximum Surface Temperature
80 °C
Included Items
Included Cables
Dedicated IP65 Powerconnection
Included Accessories
End Cap, User Manual
Included Rigging
Bracket
■メーカーサイト
https://www.highlite.com/en/42672-cameleon-flood-6-q4.html
