HIGHLITE Showtec Cameleon Flood 6 Q4 Tour RGBW [42682v]

6x 5 W RGBW LED Flood
Suitable for colour mixing on stage
IP65 (dust and water resistant, fit for temporary outdoor use)
40° fixed beam angle
Bracket and IP65 power connector included
The Showtec Cameleon Flood 6 Q4 Tour is a 6x 5 watt RGBW LED Flood with IP65 rating, suitable for indoor and temporary outdoor applications. It has a 40° fixed beam angle and features 0 - 100 % dimmer and 0 - 15 Hz strobe effects, perfectly suitable for colour mixing on stage. The Cameleon Flood 6 Q4 can be controlled manually, via DMX, Master/Slave, and IR Remote in either Manual or Auto-run mode with many available built-in programs. It is equipped with Power Pro True IP65-rated power connectors, which are compatible with the leading brands. A bracket for easy fixation is included. An infrared remote is optionally available.

仕様

Source
Light Source Type
LED
Light Source Quantity
6
Light Source Power
5 W
LED Colour Type
RGBW
Refresh Rate
1200 Hz
Luminous Flux (Total)
1337 lm
Luminous Flux (Red)
324 lm
Luminous Flux (Green)
754 lm
Luminous Flux (Blue)
124 lm
Luminous Flux (White)
579 lm
CRI
77
CCT
7200 K

Optical
Beam Angle (Horizontal)
40°
Beam Angle (Vertical)
40°

Control and Programming
Control Mode
Auto, DMX, Manual, Master Slave, Remote
DMX Channels
4, 6, 10
Protocols
DMX
Display
OLED, Touch

Dynamic Effects
Dimmer
0-100 %

Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
35 W
Power Connector In
Power Pro True
Power Connector Out
Power Pro True
DMX Connector
XLR 3P In/Out
DMX Connector In
XLR 3P
DMX Connector Out
XLR 3P

サイズ

Mechanical Specifications
Length (mm)
220 mm
Width (mm)
90 mm
Height (mm)
150 mm
Weight
3.5 kg
IP Rating
IP65
Housing
Aluminium die-cast
Colour
Black

Product Properties
Cooling
Convection

Rigging
Mounting Options
Bracket, Quick-Lock
Safety Attachment
Yes

Thermal Specifications
Maximum Ambient Temperature
45 °C
Minimum Operating Temperature
-10 °C

Included Items
Included Cables
Power Pro True Cable
Included Rigging
Quick-Lock Bracket
