HIGHLITE Showtec Spectral 300 MKIII Q4 RGBW [43561v]

Compact 20 W RGBW LED Spot
12° fixed beam angle
Dimmer and strobe function
DMX and Master/Slave control
Silent, fanless operations
The Showtec Spectral 300 MKIII Q4 is a compact 20 watt RGBW LED Spot suitable for indoor venues. Each function and effect, including its dimmer and strobe function and colour mixing engine, is controllable via DMX and Master/Slave in either Manual and Auto run mode. The Showtec Spectral 300 MKIII projects a bright, soft field of coloured light with a 12° fixed beam angle. Its compact 1.9 kg design is ideal for quick rigging on stage.

仕様

Source
Light Source Type
LED
Light Source Quantity
1
Light Source Power
20 W
LED Colour Type
RGBW
Refresh Rate
1200 Hz
Luminous Flux (Total)
800 lm

Optical
Beam Angle (Circular)
12°

Control and Programming
Control Mode
Auto, DMX, Manual, Master Slave
DMX Channels
3, 4, 5, 6, 9
Protocols
DMX
Display
7-segment

Dynamic Effects
Dimmer
0-100 %
Strobe
0-20 Hz

Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
21 W
Power Connector In
Internal Powerlink with custom power connector
DMX Connector
XLR 3P In/Out
DMX Connector In
XLR 3P
DMX Connector Out
XLR 3P
Cable Length
1.5 m

サイズ

Mechanical Specifications
Length (mm)
210 mm
Width (mm)
125 mm
Height (mm)
176 mm
Weight
1.1 kg
IP Rating
IP20 (indoor use only)
Housing
Aluminium die-cast
Colour
Black

Product Properties
Cooling
Convection

Rigging
Mounting Options
Clamp, Surface

Thermal Specifications
Maximum Ambient Temperature
40 °C
Minimum Operating Temperature
-10 °C


Included Items
Included Cables
Dedicated IP65 Powerconnection
Included Accessories
User Manual
Included Rigging
Bracket, Safety Cable

参照

■メーカーサイト
https://www.highlite.com/en/products/entertainment-lighting/spots/spots-indoor/43561-spectral-300-mkiii-q4.html
