HIGHLITE Showtec Spectral M800 Q4 IP65 RGBW [43571v]

Showtec Spectral M800 Q4 Tour. Productcode: 43570. from Highlite International on Vimeo.

Solid and reliable 14x 5 W RGBW LED Spot
16° fixed beam angle
IP65 (dust and water resistant, fit for outdoor use)
Dimmer and strobe function
DMX and Master/Slave control

仕様

Source
Light Source Type
LED
Light Source Quantity
14
Light Source Power
5 W
LED Colour Type
RGBW
Refresh Rate (Min.)
600 Hz
Refresh Rate (Max.)
25 kHz
Illuminance @ 2 m
8047 lx
Illuminance @ 3 m
3576 lx
Illuminance @ 5 m
1288 lx
Luminous Flux (Total)
2638 lm
CRI
70

Optical
Beam Angle (Circular)
16°

Control and Programming
Control Mode
Auto, Built-in Program, DMX, Manual, Master Slave
DMX Channels
4, 5, 6, 7, 9, 10, 13, 15
Protocols
DMX, RDM
Display
7-segment

Dynamic Effects
Dimmer
0-100 %
Strobe
0-20 Hz

Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
65 W
Power Connector In
powerCON TRUE1
Power Connector Out
powerCON TRUE1
DMX Connector
Dedicated 3P IP65 In/Out
DMX Connector In
Dedicated 3P IP65
DMX Connector Out
Dedicated 3P IP65
Cable Length
1.5 m

■サイズ
Mechanical Specifications
Length (mm)
180 mm
Width (mm)
235 mm
Height (mm)
320 mm
Weight
5.2 kg
IP Rating
IP65
Housing
Aluminium die-cast
Colour
Black

Product Properties
Cooling
Convection
Thread
M12

Rigging
Mounting Options
Clamp, Surface
Safety Attachment
Yes

Thermal Specifications
Maximum Ambient Temperature
40 °C
Minimum Operating Temperature
-10 °C

Included Items
Included Cables
powerCON TRUE1 cable
Included Accessories
User Manual
Included Rigging
Bracket, Safety Cable
