HIGHLITE Showtec LED Light Bar 8 RGB [42196v]
商品詳細
Batten effect
8-section control
Power and data daisy chain
Compact size
Light Source Type
LED
Light Source Quantity
240
Light Source Power
5 W
LED Colour Type
RGB
Refresh Rate
11600 Hz
Illuminance @ 2 m
613.3 lx
Luminous Flux (Total)
800 lm
Optical
Beam Angle (Horizontal)
30°
Beam Angle (Vertical)
30°
Control and Programming
Control Mode
Auto, Built-in Program, DMX, Master Slave, Sound, Stand Alone
DMX Channels
2, 3, 4, 7, 14, 26
Protocols
DMX
Display
7-segment
Dynamic Effects
Dimmer
0-100 %
Strobe
0-15 Hz
Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
23 W
Power Connector In
IEC
Power Connector Out
IEC
DMX Connector
XLR 3P In/Out
DMX Connector In
XLR 3P
DMX Connector Out
XLR 3P
Length (mm)
1070 mm
Width (mm)
65 mm
Height (mm)
88 mm
Weight
1.58 kg
IP Rating
IP20 (indoor use only)
Housing
Aluminium
Colour
Black
Product Properties
Cooling
Convection
Rigging
Mounting Options
Bracket, Clamp, Floor, Wall
Safety Attachment
No
Thermal Specifications
Maximum Ambient Temperature
40 °C
Included Items
Included Cables
IEC cable
Included Accessories
User Manual
Included Rigging
Bracket
■メーカーサイト
https://www.highlite.com/en/42196-led-light-bar-8.html
