HIGHLITE Showtec LED Light Bar 12 Pixel RGBW [42197]

Showtec Led Light Bar 12 Pixel RGBW. Ordercode: 42197. from Highlite International on Vimeo.

RGBW 4-in-1 colours
Individual pixel control
Power and data daisy chain
Compact size

仕様

Source
Light Source Type
LED
Light Source Quantity
12
Light Source Power
4 W
LED Colour Type
RGBW
Refresh Rate
2000 Hz
Illuminance @ 2 m
500 lx
Luminous Flux (Total)
500 lm

Optical
Beam Angle (Horizontal)
30°
Beam Angle (Vertical)
30°

Control and Programming
Control Mode
Auto, Built-in Program, DMX, Master Slave, Stand Alone
DMX Channels
4, 6, 10, 12, 18, 48
Protocols
DMX
Display
7-segment

Dynamic Effects
Dimmer
0-100 %
Strobe
0-20 Hz

Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
20 W
Power Connector In
IEC
Power Connector Out
IEC
DMX Connector
XLR 3P In/Out
DMX Connector In
XLR 3P
DMX Connector Out
XLR 3P

サイズ

Mechanical Specifications
Length (mm)
1080 mm
Width (mm)
65 mm
Height (mm)
88 mm
Weight
2.08 kg
IP Rating
IP20 (indoor use only)
Housing
Aluminium
Colour
Black

Product Properties
Cooling
Convection

Rigging
Mounting Options
Bracket, Clamp, Floor, Wall
Safety Attachment
No

Thermal Specifications
Maximum Ambient Temperature
40 °C

Included Items
Included Cables
IEC cable
Included Accessories
User Manual
Included Rigging
Bracket

参照

■メーカーサイト
https://www.highlite.com/en/42197-led-light-bar-12-pixel.html
