HIGHLITE Showtec Pixelbar 16Q6 RGBWA-UV [41308]
商品詳細
Showtec - Pixelbar 16 Q6. Product code 41308 from Highlite International on Vimeo.
RGBWA-UV LEDs
Individual Pixel Control
DMX and Art-Net Control
Brackets included
仕様
SourceLight Source Type
LED
Light Source Quantity
16
Light Source Power
10 W
LED Colour Type
RGBWAUV
Refresh Rate
12000 Hz
Luminous Flux (Total)
4020 lm
Optical
Beam Angle (Horizontal)
25°
Beam Angle (Vertical)
25°
Control and Programming
Control Mode
Art-Net, Auto, DMX, Manual, Master Slave, Stand Alone
DMX Channels
6, 8, 12, 96, 101
Protocols
Art-Net, DMX
Display
LCD
Dynamic Effects
Dimmer
0-100 %
Strobe
0-25 Hz
Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
170 W
Power Connector In
Power Pro Blue
Power Connector Out
Power Pro Grey
DMX Connector
XLR 3P In/Out, XLR 5P In/Out
DMX Connector In
XLR 3P, XLR 5P
DMX Connector Out
XLR 3P, XLR 5P
Data Connector In
RJ45
Data Connector Out
RJ45
サイズ
Mechanical SpecificationsLength (mm)
1047 mm
Width (mm)
136 mm
Height (mm)
146.5 mm
Weight
6.5 kg
IP Rating
IP20 (indoor use only)
Housing
Aluminium
Colour
Black
Product Properties
Cooling
Convection
Rigging
Mounting Options
Bracket, Floor, Quick-Lock, Wall
Safety Attachment
Yes
Thermal Specifications
Maximum Ambient Temperature
40 °C
Included Items
Included Cables
powerCON cable
Included Accessories
User Manual
Included Rigging
Bracket
参照
■メーカーサイト
https://www.highlite.com/en/41308-pixelbar-16q6.html
