HIGHLITE Showtec Pixel Bar 8 COB RGB [41266]

Showtec Pixel Bar 8 COB, ordercode 41266. from Highlite International on Vimeo.

3-in-1 COB LED Technology
Power and data daisy chain
Multiple DMX modes for total pixel control
Large Beam Angle

仕様

Source
Light Source Type
LED
Light Source Quantity
8
Light Source Power
15 W
LED Colour Type
RGB
Refresh Rate
7800 Hz
Luminous Flux (Total)
1050 lm

Optical
Beam Angle (Horizontal)
60°
Beam Angle (Vertical)
60°

Control and Programming
Control Mode
Auto, Built-in Program, DMX, Master Slave, Sound
DMX Channels
2, 3, 5, 6, 12, 24
Protocols
DMX
Display
7-segment

Dynamic Effects
Dimmer
0-100 %
Strobe
0-20 Hz

Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
120 W
Power Connector In
IEC
Power Connector Out
IEC
DMX Connector
XLR 3P In/Out
DMX Connector In
XLR 3P
DMX Connector Out
XLR 3P

サイズ

Mechanical Specifications
Length (mm)
735 mm
Width (mm)
110 mm
Height (mm)
85 mm
Weight
3.9 kg
IP Rating
IP20 (indoor use only)
Housing
Aluminium
Colour
Black

Product Properties
Cooling
Axial fan

Rigging
Mounting Options
Bracket, Stand

Thermal Specifications
Maximum Ambient Temperature
40 °C
Minimum Operating Temperature
-5 °C

Included Items
Included Cables
IEC cable
Included Accessories
User Manual
Included Rigging
Bracket

参照

■メーカーサイト
https://www.highlite.com/en/41266-pixel-bar-8-cob.html
