HIGHLITE Showtec Cameleon Bar 16 RGBW [42670]

Showtec Cameleon Bar 16 Q4. Productcode: 42670. from Highlite International on Vimeo.

16x 5 W RGBW LED Bar
IP65 (dust and water resistant, fit for outdoor use)
39° fixed beam angle
Dimmer and strobe function
Manual, DMX, IR and Master/Slave control

仕様

Source
Light Source Type
LED
Light Source Quantity
16
Light Source Power
5 W
LED Colour Type
RGBW
Drive Current
3.5 A
Refresh Rate
6000 Hz
Illuminance @ 2 m
2966 lx
Luminous Flux (Total)
2966 lm
Luminous Flux (Red)
640 lm
Luminous Flux (Green)
898 lm
Luminous Flux (Blue)
282 lm
Luminous Flux (White)
1287 lm

Optical
Beam Angle (Horizontal)
39°
Beam Angle (Vertical)
39°

Control and Programming
Control Mode
Auto, DMX, Master Slave
DMX Channels
4, 5, 6, 9
Protocols
DMX
Display
OLED

Dynamic Effects
Dimmer
0-100 %
Strobe
0-15 Hz

Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
75 W
Power Connector In
Dedicated IP65 Powerconnection
Power Connector Out
Dedicated IP65 Powerconnection
DMX Connector
Dedicated 3P IP65 In/Out
DMX Connector In
Dedicated 3P IP65
DMX Connector Out
Dedicated 3P IP65

サイズ

Mechanical Specifications
Length (mm)
1002 mm
Width (mm)
72 mm
Height (mm)
142 mm
Weight
6.2 kg
IP Rating
IP65
Housing
Aluminium die-cast
Colour
Black

Product Properties
Cooling
Convection

Rigging
Mounting Options
Bracket
Safety Attachment
Yes

Thermal Specifications
Maximum Ambient Temperature
40 °C

Included Items
Included Cables
Dedicated IP65 Powerconnection
Included Accessories
User Manual
Included Rigging
Bracket

参照

■メーカーサイト
https://www.highlite.com/en/42670-cameleon-bar-16.html
