HIGHLITE Showtec Cameleon Bar 15 Q6 Tour RGBWA-UV [42668]
商品詳細
Showtec - Cameleon Bar 15 Q6 Tour. Product Code 42668 from Highlite International on Vimeo.
15x 10 W RGBWA-UV LED Flood
Perfect for colour mixing on stage
IP65 (dust and water resistant, fit for outdoor use)
33°x 22° fixed beam angle
Power Pro True connectors
仕様
SourceLight Source Type
LED
Light Source Quantity
15
Light Source Power
10 W
LED Colour Type
RGBWAUV
Refresh Rate
4000 Hz
Luminous Flux (Total)
3850 lm
Optical
Beam Angle (Horizontal)
33°
Beam Angle (Vertical)
22°
Control and Programming
Control Mode
Auto, DMX, Manual, Master Slave, Remote
DMX Channels
6, 8, 12
Protocols
DMX, RDM
Display
OLED
Dynamic Effects
Dimmer
0-100 %
Strobe
0-20 Hz
Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
135 W
Power Connector In
Power Pro True
Power Connector Out
Power Pro True
DMX Connector
XLR 3P In/Out
DMX Connector In
XLR 3P
DMX Connector Out
XLR 3P
サイズ
Mechanical SpecificationsLength (mm)
1.025 mm
Width (mm)
80 mm
Height (mm)
155 mm
Weight
7.2 kg
IP Rating
IP65
Housing
Aluminium die-cast
Colour
Black
Product Properties
Cooling
Convection
Rigging
Mounting Options
Bracket
Thermal Specifications
Maximum Ambient Temperature
40 °C
Minimum Operating Temperature
-5 °C
Included Items
Included Cables
Power Pro True Cable
参照
■メーカーサイト
https://www.highlite.com/en/42668-cameleon-bar-15-q6-tour.html
