HIGHLITE Showtec Stage Blinder 1 LED [30784]
商品詳細
Showtec Stageblinder LED. Order code 30783 from Highlite International on Vimeo.
Very punchy single blinder
Tungsten simulation
Compact design
仕様
SourceLight Source Type
LED
Light Source Quantity
1
Light Source Power
80 W
LED Colour Type
WW, CW
Refresh Rate
3100 Hz
Luminous Flux (Total)
4190 lm
CCT
2490 K
Optical
Beam Angle (Horizontal)
65°
Control and Programming
Control Mode
Built-in Program, DMX
DMX Channels
1, 2
Protocols
DMX
Display
LCD
Dynamic Effects
Dimmer
0-100 %
Strobe
0-20 Hz
Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
85 W
Power Connector In
Power Pro Blue
DMX Connector
XLR 3P In/Out
DMX Connector In
XLR 3P
DMX Connector Out
XLR 3P
サイズ
Mechanical SpecificationsLength (mm)
233 mm
Width (mm)
170 mm
Height (mm)
87 mm
Weight
2 kg
IP Rating
IP20 (indoor use only)
Material
Metal
Housing
Metal, Plastic
Colour
Black
Product Properties
Cooling
Axial fan
Rigging
Mounting Options
Clamp
Safety Attachment
Yes
Safety Eyes
1
Thermal Specifications
Maximum Ambient Temperature
40 °C
Maximum Surface Temperature
70 °C
Minimum Operating Temperature
-5 °C
Included Items
Included Cables
Power Pro Cable
Included Accessories
User Manual
