HIGHLITE Showtec Dynamic LED [43056v]

42 LED matrix patterns
4-in-1 Light effect
RGBWA Colours
Wide beam angle

仕様

Source
Light Source Type
LED
Light Source Quantity
256
Light Source Power
25 W
LED Colour Type
RGBWY

Control and Programming
Control Mode
Auto, Built-in Program, DMX, Master Slave, Sound, Static Dimmer
DMX Channels
2, 3
Protocols
DMX
Display
7-segment, LED

Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
38 W
Power Connector In
IEC
DMX Connector
XLR 3P In/Out
DMX Connector In
XLR 3P
DMX Connector Out
XLR 3P

サイズ

Mechanical Specifications
Height (mm)
155 mm
Width (mm)
930 mm
Depth (mm)
150 mm
Weight
4.4 kg
IP Rating
IP20 (indoor use only)
Housing
Aluminium die-cast
Colour
Black

Product Properties
Cooling
Convection

Rigging
Mounting Options
Bracket

Thermal Specifications
Maximum Ambient Temperature
40 °C

Included Items
Included Cables
IEC cable
Included Rigging
Bracket
