HIGHLITE Showtec Dynamica [43162]

Showtec Dynamica. Ordercode: 43162. from Highlite International on Vimeo.

4-in-1 light effect
Dual RG laser grating effects
RGBWA LED pattern beams
Dual strobe arrays
Dual UV wash effect

仕様

Source
Light Source Type
Diode, DPSS, LED
Light Source Quantity
192
Light Source Quantity (Effect)
2
Light Source Power
12 W
Light Source Power (Effect)
3 W
LED Colour Type
UV, RGBWA, White
LED Strobe
Yes
LED Strobe Quantity
18
Laser Class
2M
Laser Colour
Red, Green
Laser Power (Total)
260 mW
Laser Power (Red)
200 mW
Laser Wavelength (Red)
650 nm
Laser Power (Green)
60 mW
Laser Wavelength (Green)
532 nm

Control and Programming
Control Mode
Auto, DMX, Master Slave, Remote, Sound
DMX Channels
2, 5, 8, 10
Protocols
DMX
Display
7-segment, LED

Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
40 W
Power Connector In
IEC
Power Connector Out
IEC
DMX Connector
XLR 3P In/Out
DMX Connector In
XLR 3P
DMX Connector Out
XLR 3P

サイズ

Mechanical Specifications
Height (mm)
225 mm
Width (mm)
770 mm
Depth (mm)
175 mm
Weight
5.5 kg
IP Rating
IP20 (indoor use only)
Housing
Aluminium die-cast
Colour
Black

Product Properties
Cooling
Convection/Axial fan
Safety Features
Interlock, Key Switch, Safety Eye

Rigging
Mounting Options
Clamp
Safety Attachment
Yes

Thermal Specifications
Maximum Ambient Temperature
40 °C
Product Compliance
Laser Classification Standard
EN-IEC 60825-1:2014

Included Items
Included Cables
IEC cable
Included Rigging
Bracket
Included Remotes
IR Remote

参照

■メーカーサイト
https://www.highlite.com/en/products/entertainment-lighting/light-effects/effect-lights/43162-dynamica.html
