HIGHLITE Showtec Dataflower [43168]

Showtec Dataflower. Product code 43168 from Highlite International on Vimeo.

100 W High Power LED
Dynamic Sound to Light Control
DMX, manual, Master/slave and sound control
Superb Aerial Effects

仕様

Source
Light Source Type
LED
Light Source Quantity
1
Light Source Power
100 W
CCT
7400 K

Optical
Beam Angle (Circular)
40°

Control and Programming
Control Mode
Auto, Built-in Program, DMX, Master Slave, Sound
DMX Channels
2, 5, 7
Protocols
DMX
Display
7-segment, LED

Dynamic Effects
Dimmer
0-100 %
Strobe
0-20 Hz
Colour System
Colour Wheel
Colour Wheel Index & Rotate
Yes
Dichroic Colour Wheel 1
9 + Open
Gobo Wheel Index & Rotate
Yes
Gobo Wheel 1
11 + Open

Movement
Continuous Movement
Mirror Disc Bi-directional

Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
117 W
Power Connector In
IEC
Power Connector Out
IEC
DMX Connector
XLR 3P In/Out
DMX Connector In
XLR 3P
DMX Connector Out
XLR 3P

サイズ

Mechanical Specifications
Height (mm)
202 mm
Width (mm)
265 mm
Depth (mm)
308 mm
Weight
4 kg
IP Rating
IP20 (indoor use only)
Housing
Metal
Colour
Black

Product Properties
Cooling
Axial fan
Safety Features
Safety Eye

Rigging
Mounting Options
Clamp
Safety Attachment
Yes

Thermal Specifications
Maximum Ambient Temperature
40 °C

Included Items
Included Cables
IEC cable
Included Rigging
Bracket

参照

■メーカーサイト
https://www.highlite.com/en/products/entertainment-lighting/light-effects/effect-lights/43168-dataflower.html
