HIGHLITE Showtec Hydrogen DMX MKII [43151v]

20 W LED Source
Red, Green, Blue, Purple, Yellow and White
4 DMX channels
Multi-voltage

仕様

Source
Light Source Type
LED
Light Source Quantity
1
Light Source Power
20 W

Optical
Beam Angle (Circular)
25°

Control and Programming
Control Mode
Auto, DMX, Master Slave
DMX Channels
4
Protocols
DMX
Display
7-segment, LED
Dynamic Effects
Dimmer
0-100 %
Strobe
0-20 Hz

Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
35 W
Power Connector In
IEC
Power Connector Out
IEC
DMX Connector
XLR 3P In/Out
DMX Connector In
XLR 3P
DMX Connector Out
XLR 3P

サイズ

Mechanical Specifications
Height (mm)
135 mm
Width (mm)
275 mm
Depth (mm)
250 mm
Weight
3.5 kg
IP Rating
IP20 (indoor use only)
Housing
Metal, Plastic
Colour
Black

Product Properties
Cooling
Convection
Safety Features
Safety Eye

Rigging
Mounting Options
Clamp
Safety Attachment
Yes

Thermal Specifications
Maximum Ambient Temperature
40 °C

Included Items
Included Cables
IEC cable
Included Rigging
Bracket

参照

■メーカーサイト
https://www.highlite.com/en/products/entertainment-lighting/light-effects/effect-lights/43151-hydrogen-dmx-mkii.html
