Advatek Light PixLite R4D-S（アドバテック ライト）

The PixLite R4D-S makes creating brilliant light shows in demanding settings a breeze. For professionals looking to make that ‘peace of mind’ purchase that makes installing and running complex displays easy, you can’t go past this long-distance pixel receiver device.
When used in tandem with the PixLite T8 Controller, the PixLite R4D-S can serve as the receiver of differential pixel data and convert it into a pixel ready signal. A long-distance capability is all you could need to open up a broad range of possibilities and make brilliant displays possible.

■特徴
Industrial grade fault protection
Receive data up to 300+m from PixLite T8-S
Power in and fuse good indicators
Compact form factor
Sleek design with flip lid access to all fuses
Din-rail and wall mountable

■4 Dedicated Pixel Outputs
4 individually fused outputs suitable for data only (3 wire) pixel LEDS, each with up to 510 RGB pixels. Requires any compatible PixLite T8-S transmitter unit to be configured in expanded mode.

■Small Form Factor
Compact, lightweight, slimline unit designed for mounting in tight spaces.

■Fault Protection
The PixLite R4D-S Receiver features industrial strength fault protection on all inputs and pixel outputs. This makes this PixLite device far less prone to failure over time. Short circuit and ESD protection as well as protection against common DC voltage levels provides peace of mind for commercial and industrial installations.
Each output also includes a 7.5A mini blade fuse which will help protect the LEDs and power supply in a fault condition keeping the installation safe. A built-in spare fuse ensures there is always a quick replacement on hand.

■Quick Connect Power
A high current clamp connector permits you to quickly and reliably connect power.
■What About Mounting Options?
The PixLite R4D-S Receiver can be securely placed using the mounting holes in each corner of the receiver device. Using all four mounting points, you’ll have a secure hold for that set-and-forget peace of mind you want in demanding professional lighting installations.
Alternatively use the Din-Rail Mounting Kit

■■仕様
■Power
Input Voltage: 5V-24V DC
Per Output Current Limit: 7.5A (mini blade fuse)

■Protection
ESD: All inputs and outputs protected
Data Input: +/- 24V DC fault protection
Pixel Output Data Lines: +/- 24V DC fault protection
Pixel Output Power Lines: Over current and short circuit protection
Power Input: Reverse polarity protection

■Physical
Fused Pixel Outputs: 4
Data Inputs (from PixLite Transmitter): 1
Case: High Strength ABS - Black
Ambient Operating Temperature: -20°C to +55°C
Mounting: Directly mountable to wall or plate
Accessories: Din-Rail mounting bracket optional extra

■Protection
ESD: All inputs and outputs protected
Data Input: +/- 24V DC fault protection
Pixel Output Data Lines: +/- 24V DC fault protection
Pixel Output Power Lines: Over current and short circuit protection
Power Input: Reverse polarity protection

■Data
Data Only Pixel Outputs: 4
Clocked Pixel Outputs: 0
Indicative Data Limits (set by transmitter):
RGB Pixels/Output: 510
RGBW Pixels/Output: 384
sACN Universes: 12
Art-net Universes: 12

■サイズ
Length: 95mm
Width: 78mm
Height: 33mm
Weight: 0.2Kg



■メーカーサイト
https://www.advateklights.com/pixlite-r4d-s-long-range-receiver
