Chauvet Professional Nexus 4x4 [中古: ITEM #20800]

Chauvet Professional Nexus 4x4 [中古: ITEM #20800]

販売価格: 147,990円(税別)

(税込価格: 162,789円)

Nexus 4×4 is an award winning LED wash panel combining the sizzle of pixel mapping and a robust light output afforded by 16 27 W COB tri-colored LEDs. The combination of COB emitters and a clever reflector design yields a striking, diffused light richly drenched in saturated hues. Nexus 4×4 is controllable via Art-Net, Kling-Net and DMX protocols and features interlocking hardware to build large arrays. Whether in use for front viewing or as a backdrop, Nexus 4×4 promises a hard-to-match visual impact.

■概要
・Pixel-mapping RGB blinder allows you to achieve vibrant colors with bright COB LEDs
・Increase pixel mapping options by controlling pixels individually
・Build large arrays by linking multiple panels together with integrated locks
・Works seamlessly with Nexus 2x2 and Nexus 4x1
・Design with flexible control options: Kling-Net, Art-Net, or DMX
・Use universal power connectors: Neutrik powerCON, Neutrik etherCON, 3- and 5-pin XLR DMX

■■仕様
■OPTICAL
・Light Source: 16 LEDs (tri-color RGB) 27 W, (2 A), 50,000 hours life expectancyColor Temperature (range): 2,800 to 10,000 KBeam Angle: 45°Field Angle: 75°Illuminance (total): 484 lux @ 5 mPixels: 4 x 4Pixel Pitch: 115 mmPixel Density: 64/m2

■DYNAMIC EFFECTS
・Dimmer: ElectronicStrobe Rate: 0 to 20 HzStandalone Color Mixing: YesBuilt-in Automated Programs: Yes

■CONSTRUCTION / PHYSICAL
・Dimensions (single unit): 462 x 168 x 462 mm
・Dimensions (roadcase): 965 x 525 x 700 mm
・Weight (single unit): 13 kg
・Weight (roadcase): 37 kg
・Exterior Color: BlackHousing Material: Aluminum alloy and steel

■CONNECTIONS
・Power Connection: Edison (Local) plug to Neutrik powerCONPower Input: Neutrik powerCONPower Output: Neutrik powerCONData Connectors: 3- and 5-pin XLR, Neutrik etherCONCable Length (power): 5 ft (1.5 m)

■CONTROL
・Control Protocol: Art-Net, Kling-Net, DMXDMX Channels: 3, 5, 9, 48 or 53Art-Net Channels: 48

■ELECTRICAL
・Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)Power Linking: 4 units @ 120 V; 7 units @ 208 V; 8 units @ 230 VPower and Current: 401 W, 3.35 A @ 120 V, 60 HzPower and Current: 393 W, 1.90 A @ 208 V, 50 HzPower and Current: 394 W, 1.71 A @ 230 V, 50 Hz

■クイックリファレンスガイド(英語)
https://www.chauvetprofessional.com/wp-content/uploads/2015/06/Nexus_4x4_QRG_Rev6_ML4_WO.pdf

■マニュアル(英語)
https://www.chauvetprofessional.com/wp-content/uploads/2015/06/Nexus_4x4_UM_Rev4_WO-1.pdf

■メーカーサイト
https://www.chauvetprofessional.com/products/nexus-4x4/
