Chauvet Professional EPIX Strip IP 50 [新品]

Chauvet Professional EPIX Strip IP 50 [新品]

販売価格: 46,990円(税別)

(税込価格: 51,689円)

台数割引
複数台お買い上げの場合台数に応じてお値段が下がります!


無料メンテナンス

当サイトからご購入された機材を無料で1年間保証期間中修理サービスをいたします。
無料保証期間後も、ご購入された機材に不具合が生じた場合もしくは定期メインテナンスのご利用も可能です。
保証サービス:

販売価格: 46,990円(税別)

(税込価格: 51,689円)

数量:
?PIX Strip IP 50 is an IP65 outdoor-rated pixel-mapping ? meter LED strip fixture, featuring 50 LEDs. Ideal for use in tight spaces, this versatile fixture also comes with dome and flat accessories and stunning pre-built content to allow you to easily configure and program shows in minutes with minimum time/effort. Power and control it through our new ?PIX Drive 2000 IP on Art-Net, Kling-Net, or sACN (streaming ACN).

■概要
・Pixel-mapping IP65 outdoor half-meter 50 x 1 LED strip for showing video and/or motion graphics
・Includes square milky filter (installed) for diffused output, round milky filter (included) for diffused output, and black stealth filter (included) for high contrast
・Uses specialized LED dimming control via S-PWM (scrambled PWM), which enhances on-camera performance.
・Versatile control options include Art-Net, Kling-Net, and sACN (streaming ACN) to support the touring, rental, and installation markets
・Reduce programming time and increase application by using the alternate personalities of 7 channel, multi-section control (15-30 channels), or use the Pixel personality (150 channels) for use with video servers
・Increase viewing angle by using the dome or square accessory
・?PIX Drive 2000 IP required for operation

■■仕様
■OPTICAL
・Light Source: 50 LEDs (tri-color RGB) SMD 5050, 50,000 hours life expectancy
・Viewing Angle (with installed Square Milky Filter): 160°
・Viewing Angle (with optional Round Milky Filter): 160°
・Viewing Angle (with optional Black Stealth Filter): 125°
・Illuminance ? open: 8,640 NITS
・Illuminance - Square Milky Filter (installed): 2,470 NITS
・Illuminance - Black Stealth Filter (included): 1,455 NITS
・Illuminance ? Round Milky Filter (included): 1,360 NITS
・Pixels: 50 x 1
・Pixel Pitch: 10 mm
・Refresh Rate: 4,800 Hz (S-PWM)

■CONSTRUCTION / PHYSICAL
・Dimensions (with installed Square Milky Filter ): 500 x 34 X 100 mm
・Dimensions: (with included Black Stealth Filter): 500 x 34 x 88 mm
・Dimensions (with included Round Milky Filter): 500 x 45 x128 mm
・Weight: 1.5 kg
・Exterior Color: Black
・Housing Material: Aluminum

■CONNECTIONS
・Data Connectors: IP-65 4-pin XLR
・Physical Linking: 20 inline ?PIX Strip IP per port of Drive 2000 IP
・Minimum required device linking cable size: 4 conductor (2 x 14 AWG, 2 x 16 AWG)
・Total max. cable length (shielded cables) between ?PIX Drive 2000 IP and last ?PIX IP fixture: 64 m
・Max. cable length (shielded cables) between ?PIX Drive 2000 IP and first ?PIX IP fixture: 20 m
・Max. cable length (shielded cables) between ?PIX IP fixtures: 18 m
・Total max. cable length (unshielded cables) between ?PIX Drive 2000 IP and last ?PIX IP fixture: 91 m
・Max. cable length (unshielded cables) between ?PIX Drive 2000 IP and first ?PIX IP fixture: 45 m
・Max. cable length (unshielded cables) between ?PIX IP fixtures: 30 m

■CONTROL
・Control Protocol: Art-Net, Kling-Net, sACN
・Control Channels Art-net, sACN: 7, 15, 30, 75, or 150

■ELECTRICAL
・Power and Current: 16 W, 0.133 A @ 120 V, 60 Hz
・Power and Current: 17 W, 0.082 A @ 208 V, 60 Hz
・Power and Current: 17 W, 0.073 A @ 230 V, 50 Hz

■CERTIFICATIONS / QUALIFICATIONS
・CE, MET
・IP Rating: IP65, outdoor/wet
・Temperature (Ambient): -20 °C to 45 °C

■WHAT'S INCLUDED
・?PIX Strip IP 50
・Square milky filter (installed)
・Round milky filter (included in box)
・Black stealth filter (included in box)

■REQUIRED ACCESSORIES
・Controller (required): ?PIX Drive 2000 IP
・Compatible Mounting Options: M12 Bolt/Clamp (rear mounting)

■OPTIONAL ACCESSORIES
・ArKaos Media Master Express + KN software
・ClampsNeutrik powerCON cables
・Neutrik etherCON cables

■クイックリファレンスガイド(英語)
https://www.chauvetprofessional.com/wp-content/uploads/2018/10/%C3%89PIX_Strip_IP_50_QRG_Rev2_ML4.pdf

■メーカーサイト
https://www.chauvetprofessional.com/products/epix-strip-ip-50/
