Ovation B-1965FC takes advantage of the extended color capabilities and superior color renderings of the RGBA-Lime color mixing system to offer an ideal 1.2 m batten for stage and theatre lighting. It responds to RDM, Art-Net? and sACN in addition to standard DMX control. Up to seven sections can be controlled individually for maximum flexibility. An easily accessible Virtual Color Wheel and Color Temperature Presets make programming a breeze. It comes with a holographic filter that easily locks into place for enhanced wall/cyc grazing ability.

■概要
・Full Color LED (RGBAL) batten fixture for theatre, film and production
・Theatre-ready with 16-bit dimming of master dimmer and individual colors
・Multiple control personalities for complex programming schemes up to 7 sections of control
・Included holographic filter for use in cyc lighting or wall grazing applications for ultra-smooth color mixing
・Virtual Color wheel with color matched to popular gel colors
・Art-Net?, sACN, 3- and 5-pin DMX and RDM (Remote Device Management) for added control flexibility
・Neutrik powerCON and Amphenol etherCON compatible connections for power and data linking
・Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
・Nearly silent operation for use in studio and theatre applications

■■仕様
■OPTICAL
・Light Source: 196 LEDs (42 red, 42 green, 42 blue, 28 amber, 42 lime) 3 W (650 mA), 50,000 hours life expectancy
・Color Temperature (range): 2800 to 10000 K
・CRI (3200 K): 80
・Installed Optics: 20°
・Beam Angle (Horizontal): 24°
・Beam Angle (Vertical): 21°
・Beam Angle (Horizontal w/filter): 44°
・Beam Angle (Vertical w/filter): 22°
・Field Angle(Horizontal): 41°
・Field Angle (Vertical): 37°
・Field Angle (Horizontal w/filter): 75°
・Field Angle (Horizontal w/filter): 41°
・Lumens: 22,925
・Illuminance: 5,000 lux @ 5 m
・Illuminance (w/filter): 1,720 lux @ 5 m
・Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz

■DYNAMIC EFFECTS
・Dimmer: Electronic
・Shutter/Strobe: Electronic
・Strobe Rate: 0 to 30 Hz
・Standalone Color Mixing: Yes
・Color Temperature Presets: Yes
・Dim Modes: 4
・Built-in Automated Programs: Yes

■CONSTRUCTION / PHYSICAL
・Dimensions: 1230 x 210 x 207 mm
・Weight: 14.5 kg
・Exterior Color: Black
・Housing Material: Aluminum die-cast
・Accessory Holder/Gel Frame Size: 1206 x 93 mm

■CONNECTIONS
・Power Connection: Edison (Local) plug to Neutrik powerCON
・Power Input: Neutrik powerCON
・Power Output: Neutrik powerCON
・Data Connectors: 3- and 5-pin XLR, Amphenol etherCON Compatible
・Cable Length (power): 1.5 m

■CONTROL
・Protocol(s): Art-Net?, DMX, RDM, sACN
・DMX Channels: 1 Cell: 3, 3, 4, 5, 8, 9, 10, 10, 17
7 Cell: 21, 28, 35, 45, 52, 59, 70, 96
・Art-Net Channels: 1 Cell: 3, 3, 4, 5, 8, 9, 10, 10, 17
7 Cell: 21, 28, 35, 45, 52, 59, 70, 96
・Modes/Personalities: 17 personalities

■ELECTRICAL
・Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
・Power Linking: 3 units @ 120 V; 6 units @ 208 V; 7 units @ 230 V
・Power and Current: 421 W, 3.559 A @ 120 V, 60 Hz
・Power and Current: 427 W, 2.066 A @ 208 V, 60 Hz
・Power and Current: 429 W, 1.863 A @ 230 V, 50 Hz
・Power and Current (resting): 26 W, 0.211 A @ 120 V, 60 Hz
・Power and Current (resting): 46 W, 0.220 A @ 208 V, 60 Hz
・Power and Current (resting): 47 W, 0.199 A @ 230 V, 50 Hz

■CERTIFICATIONS / QUALIFICATIONS
・CE, MET, FCC
・IP Rating: IP20, dry location
・Temperature (Ambient): -20 °C to 45 °C

■OPTIONAL ACCESSORIES
・Professional Clamps: CTC-50HC, CTC-50HCN
・Neutrik powerCON cables
・Neutrik etherCON cables
・DMX Cables

■ORDERING INFO
・Item Code: 03031296

■クイックリファレンスガイド(英語)
https://www.chauvetprofessional.com/wp-content/uploads/2015/01/Ovation_B-1965FC_QRG_ML4_Rev7.pdf

■マニュアル(英語)
https://www.chauvetprofessional.com/wp-content/uploads/2015/01/Ovation_B-1965FC_UM_Rev5.pdf

■メーカーサイト
https://www.chauvetprofessional.com/products/ovation-b-1965fc/
