Ovation E-930VW is a high-performance, variable white ellipsoidal style fixture that utilizes our unique 6-color LED system. This fixture projects a bright, beautifully flat field of light in nearly any temperature of white with high CRI and CQS. Each Color Temperature can be further adjusted for +/- green to perfect the field of light. For times when a splash of color is needed, the fixture can also give you full control of each color of LED as well.

■概要
・Variable white ERS-style lighting fixture for theatre, film and production
・Color Temperature Presets from 2800 K to 8000 K with high CRI and CQS
・Beautiful 16-bit dimming
・Proprietary LED engine delivers tremendous, equal output at all color temperatures
・+/- Green adjustment via DMX or on-board control
・Independent color control over the 6-color engine when a splash of color is needed
・RDM (Remote Device Management) for added flexibility
・Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
・Virtually silent operation for use in studio and theatre applications
・Works perfectly with industry standard lens tubes and accessories

■■仕様
■OPTICAL
・Light Source: 91 LEDs (6 red, 15 orange-red, 9 green, 12 blue, 10 royal blue, 39 lime) 3 W, (960 mA), 50,000 hours life expectancy
・Color Temperature (range): 2800 to 8000K
・CRI: 88-92
・Beam Angle (w/14° lens): 12°
・Beam Angle (w/19° lens): 17°
・Beam Angle (w/26° lens): 22°
・Beam Angle (w/36° lens): 27°
・Beam Angle (w/50° lens): 38°
・Beam Angle (w/15°?30° lens)(Narrow): 10°
・Beam Angle (w/15°?30° lens)(Wide): 22°
・Beam Angle (w/25°?50° lens)(Narrow): 20°
・Beam Angle (w/25°?50° lens)(Wide): 36°
・Field Angle (w/14° lens):14°
・Field Angle (w/19° lens):18°
・Field Angle (w/26° lens): 25°
・Field Angle (w/36° lens): 33°
・Field Angle (w/50° lens): 50°
・Field Angle (w/15°?30° lens)(Narrow): 14°
・Field Angle (w/15°?30° lens)(Wide): 29°
・Field Angle (w/25°?50° lens)(Narrow): 22°
・Field Angle (w/25°?50° lens)(Wide): 39°
・Lumens (w/14° lens): 4,399
・Lumens (w/19° lens): 4,817
・Lumens (w/26° lens): 5,485
・Lumens (w/36° lens): 5,306
・Lumens (w/50° lens): 5,037
・Illuminance (w/14° lens): 7,560 lux @ 5 m
・Illuminance (w/19° lens): 3,765 lux @ 5 m
・Illuminance (w/26° lens): 2,210 lux @ 5 m
・Illuminance (w/36° lens): 1,296 lux @ 5 m
・Illuminance (w/50° lens): 537 lux @ 5 m
・Illuminance (w/15°?30° lens)(Narrow): 6,990 lux @ 5 m
・Illuminance (w/15°?30° lens)(Wide): 1,815 lux @ 5 m
・Illuminance (w/25°?50° lens)(Narrow): 2,464 lux @ 5 m
・Illuminance (w/25°?50° lens)(Wide): 975 lux @ 5 m
・Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz

■DYNAMIC EFFECTS
Dimmer: ElectronicShutter/Strobe: ElectronicStrobe Rate: 0 to 28 HzFocus: ManualStandalone Color Mixing: YesColor Temperature Presets: YesDim Modes: 4Built-in Automated Programs: No

■CONSTRUCTION / PHYSICAL
Dimensions (fixture only): 25.04 x 13.54 x 23.22 in (636 x 344 x 590 mm)Dimensions (w/26° lens extended): 28.06 x 13.54 x 23.22 in (800 x 344 x 590 mm)Dimensions (w/15°?30° lens): 37 x 11.52 x 10.33 in (939.8 x 287.9 x 262.62 mm)Dimensions (w/25°?50° lens): 29.75 x 11.52 x 10.33 in (755.65 x 287.9 x 262.62 mm)Weight (fixture only): 16.6 lb (7.5 kg)Weight (w/14° lens): 22 lb (9.97 kg)Weight (w/26° lens): 20.6 lb (9.34 kg)Weight (w/15°?30° lens): 29.2 lb (13.24 kg)Weight (w/25°?50° lens): 26.2 lb 11.88 kg)Exterior Color: BlackAccessory Holder/Gel Frame Size (14°, 19°, 26°, 36°, and 50° lens): 6.25 in (159 mm)Accessory Holder/Gel Frame Size (15°?30° lens): 7.5 in (191 mm)Accessory Holder/Gel Frame Size (25°?50° lens): 7.5 in (191 mm)

■CONNECTIONS
Power Connection: Edison (Local) plug to Neutrik? powerCON?Power Input: Neutrik? powerCON?Power Output: Neutrik? powerCON?Data Connectors: 3- and 5-pin XLRCable Length (power): 5 ft (1.5 m)

■CONTROL
Control Protocol: DMX, RDMDMX Channels: 3, 5, 6, 8, 11, 15, 17Modes/Personalities: 6 personalities (3, 5, 6, 8, 11, 15, 17)

■ELECTRICAL
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)Power Linking: 6 units @ 120 V; 10 units @ 208 V; 11 units @ 230 VPower and Current: 226 W, 2.253 A @ 120 V, 60 HzPower and Current: 272 W, 1.303 A @ 208 V, 60 HzPower and Current: 272 W, 1.192 A @ 230 V, 50 Hz

■CERTIFICATIONS / QUALIFICATIONS
CE, MET, FCCIP Rating: IP20, dry location

■WHAT'S INCLUDED
Ovation E-930VWNeutrik? powerCON? power cord

■REQUIRED ACCESSORIES
Ovation Ellipsoidal HD Lens Tubes

■OPTIONAL ACCESSORIES
Professional Clamps: CTC-50HC, CTC-50HCNNeutrik powerCON cables3-pin or 5-pin DMX CablesColor Blending Filters: DF60X1D, DF20DRDM2goOvation Zoom Lenses: OHDZOOM1530, OHDZOOM2550Gobo Holder: Ovation B-Size Metal or Glass Gobo HolderIris: Ovation 20-leaf Iris

■ORDERING INFO
Item Code: 03121411

■備考
・先玉レンズは別途ご購入となります。

・Chauvet Professional Ovation Ellipsoidal HD Lens Tubes
https://www.urakataya.com/product/13859

・Chauvet Professional Ovation Ellipsoidal HD Zoom Lenses
https://www.urakataya.com/product/13858

■クイックリファレンスガイド(英語)
https://www.chauvetprofessional.com/wp-content/uploads/2015/01/Ovation_E-930VW_QRG_ML5_Rev7.pdf

■マニュアル(英語)
https://www.chauvetprofessional.com/wp-content/uploads/2015/01/Ovation_E-930VW_UM_Rev4.pdf

■メーカーサイト
https://www.chauvetprofessional.com/products/ovation-e-930vw/
