Chauvet Professional Ovation FD-205WW [新品]

Chauvet Professional Ovation FD-205WW [新品]

販売価格: 260,990円(税別)

(税込価格: 287,089円)

台数割引
複数台お買い上げの場合台数に応じてお値段が下がります!


無料メンテナンス

当サイトからご購入された機材を無料で1年間保証期間中修理サービスをいたします。
無料保証期間後も、ご購入された機材に不具合が生じた場合もしくは定期メインテナンスのご利用も可能です。
保証サービス:

販売価格: 260,990円(税別)

(税込価格: 287,089円)

数量:
Ovation FD-205WW is a powerful LED Fresnel wash utilizing data and power sensors that make it possible to run it on both conventional dimming power systems and constant power rigs. A massive zoom range of 20° to 72° and a beautifully soft, warm white wash with high CRI make it an ideal LED replacement for aging incandescent eight-inch Fresnels. Our proprietary motorized zoom is easily accessed by the rotary knob on the back of the fixture even when the fixture is run via a traditional dimming system. Enjoy the benefits of LED lighting without being held back by previous investments made in major dimming systems!

■概要
・Works perfectly on conventional dimmers or constant power with DMX
・Auto-senses what kind of system (dimmers or constant power with DMX) and responds appropriately
・Superior low end dimming regardless of power supplied (conventional dimmer/constant power with DMX)
・Perfect fixture for the retrofit market, utilizes existing infrastructure flawlessly
・Motorized zoom feature available in Dimmer, SENS or DMX modes
・16-bit dimming resolution (DMX mode) for smooth fades
・Soft and even field of light
・Virtually silent operation for use in any situation
・Simple and complex DMX channel profiles for programming versatility
・Warm white Fresnel-style lighting fixture
・Motorized zoom angle between 20° to 72°, manually or via DMX

■■仕様
■OPTICAL
・Light Source 1 LEDs (WW) 230 W, (2.5 A), 3069 K, 50,000 hours life expectancy
・Color Temperature (at full): 3069 K
・CRI: 96
・Beam Angle: 11° to 53°
・Field Angle: 20° to 72°
・Zoom Angle: 20° to 72°
・Lumens (20°): 6,414
・Lumens (72°): 9,047
・Illuminance (20°): 5,678 lux @ 5 m
・Illuminance (72°): 450 lux @ 5 m
・Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz

■DYNAMIC EFFECTS
・Dimmer: Electronic or External Dimmer Rack
・Shutter/Strobe: Electronic
・Zoom: Motorized
・Strobe Rate: 0 to 18 Hz
・Dim Modes: 5
・Dim Curves: 4

■CONSTRUCTION / PHYSICAL
・Dimensions: 412 x 284 x 261 mm
・Weight: 6.4 kg
・Exterior Color: Black
・Accessory Holder/Gel Frame Size: 191 mm

■CONNECTIONS
・Power Connection: Edison (Local) plug to Neutrik powerCON
・Power Input: Neutrik powerCON
・Power Output: Neutrik powerCON
・Data Connectors: 3- and 5-pin XLR
・Cable Length (power): 1.5 m

■CONTROL
・Control Protocol: DMX, RDM, Dimmer
・DMX Channels: 1, 2 or 5
・Modes/Personalities: 3 personalities (UNO, DOS, STD-P)

■ELECTRICAL
・Input Voltage: 120/230 VAC, 50/60 Hz (switchable)
・Power Linking: 8 units @ 120 V; 16 units @ 230 V
・Power and Current: 182 W, 1.52 A @ 120 V, 60 Hz
・Power and Current: 188 W, .819 A @ 230 V, 50 Hz
・Breaker Size: T3.15 A, 250 V

■CERTIFICATIONS / QUALIFICATIONS
・CE, MET
・IP Rating: IP20, dry location
・Temperature (Ambient): -20 °C to 45 °C

■WHAT'S INCLUDED
・Ovation FD-205WW
・Neutrik powerCON power cord
・Gel frame (7.5 in/190.5 mm accessories)

■OPTIONAL ACCESSORIES
・Professional Clamps: CTC-50HC, CTC-50HCN
・Neutrik powerCON cables
・3-pin or 5-pin DMX Cables
・Color Blending Filters: DF60X1D, DF20D
・Ovation F 7.5″ Barndoor

■ORDERING INFO
・Item Code: 01031456

■クイックリファレンスガイド(英語)
https://www.chauvetprofessional.com/wp-content/uploads/2018/04/Ovation_FD-205WW_QRG_Rev1_ML4_WO.pdf

■マニュアル(英語)
https://www.chauvetprofessional.com/wp-content/uploads/2018/04/Ovation_FD-205WW_UM_Rev1_WO.pdf

■メーカーサイト
https://www.chauvetprofessional.com/products/ovation-fd-205ww/
