Chauvet Professional Synapse 4（ショーベー プロフェッショナル シナプス） [新品]

Synapse 4 functions as an intelligent relay pack to control the power sent to individual lighting units. Synapse 4 can de-power entire sections of an installation, which prolongs the lifespan of lighting fixtures and decreases overall power consumption, saving energy and money. Rack, truss or wall mountable, Synapse 4 also offers flexible options to control its four outputs: 1) via DMX; 2) upon sensing the loss of the DMX signal; 3) via an internal scheduler that can be used to specify that individual outputs be turned on/off. As an added convenience, a 4-port DMX opto-isolator allows users to easily branch their DMX universe in multiple directions and amplify the signal after a long cable run.

■特徴
・Controllable powerCON relay pack and DMX optically isolated splitter/amplifier
・Compounds the savings of LED fixtures by completely removing power when not in use
・Individually control all 4 relays via DMX, DMX sensing or internal scheduler for specific on/off times every day
・Optically isolated 5-pin DMX splitter provides an easy hub for running DMX to multiple locations
・Convenient mounting options; rack mount, wall mount or clamped to truss

■■仕様
■CONSTRUCTION / PHYSICAL
・Dimensions: 483 x 200 x 44.5 mm
・Weight: 2.8 kg
・Exterior Color: Black
・Rackmount: 1U

■CONNECTIONS
・Power Connection: Edison (Local) plug to Neutrik powerCON
・Power Input: Neutrik powerCON
・Power Output: Neutrik powerCON
・Data Connectors: 5-pin XLR
・Cable Length (power): 5 ft (1.5 m)

■CONTROL
・Control Protocol: DMX
・DMX Channels: 1 or 4

■ELECTRICAL
・Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
・Main breaker size: 20 A, 250 V
・Breaker size per output: 20A, 250 V

■CERTIFICATIONS / QUALIFICATIONS
・CEIP Rating: IP20, dry location

■WHAT'S INCLUDED
・Synapse 4
・Neutrik powerCON power cord

■OPTIONAL ACCESSORIES
・Professional Clamps: CTC-50HC, CTC-50HCN
・Neutrik powerCON cables
・5-pin DMX Cables

■マニュアル
https://www.chauvetprofessional.com/wp-content/uploads/2018/01/Synapse_4_UM_Rev3.pdf

■メーカーサイト
https://www.chauvetprofessional.com/products/synapse-4/
